PHOENIX CONTACT FKC 2,5/ 3-STF-5,08BD:+-GNDQ FKC 2,5/ 3-STF-5,08BD:+ GNDQ 1107074 PHOENIX CONTACT Connector for printed circuit board, number of poles: 3.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FKC 2,5/ 3-STF-5,08BD:+ GNDQ 1107074 PHOENIX CONTACT Connector for printed circuit board, number of poles: 3..

FKC 2,5/ 3-STF-5,08BD:+-GNDQ

1107074

PHOENIX CONTACT

50 Pcs.

Connector for printed circuit board, number of poles: 3, pitch: 5,08 mm, color: green Connector for printed circuit board, nominal section: 2.5 mm², color: green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of rows: 1, number of poles: 3, family of articles: FKC 2.5/.. -STF, pitch: 5.08 mm, connection type: Push-in spring connection, conductor/printed circuit board connection direction: 0°, clamping hook: - Clamping hook, plug-in system: COMBICON MSTB 2.5, locking: Screw locking, fixing type: Air clamping (screw), packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Technical data
Item Properties
Product TypePrinted Circuit Board Connector
Product FamilyFKC 2,5/.. -STF
Product LineCOMBICON Connectors M
Number of poles3
Step5.08 mm
Number of rows1
Data Maintenance Status
Article Review00
Electrical Properties
Nominal Current IN12 A
Nominal voltage UN320 V
Contact resistance1 mΩ
Sizing voltage (III/3)320 V
Dimensioning transient voltage (III/3)4 kV
Dimensioning voltage (III/2)320 V
Dimensioning Transient Voltage (III/2)4 kV
Nominal voltage (II/2)630 V
Dimensioning transient voltage (II/2)4 kV
Connection data
Connection technology
Connector SystemCOMBICON MSTB 2.5
Nominal Section2.5 mm²
Contact Connection TypeFemale
Blockade
Locking systemScrew lock
Clamping flangeOverhead clamping (screw)
Tightening torque0.3 Nm
Connecting Conductors
Connection typePush-in spring connection
Connection direction of the conductor with respect to the plug direction0 °
Connection Direction Driver/PCB0 °
Rigid conductor section0.2 mm² ... 2.5 mm²
Flexible conductor section0.2 mm² ... 2.5 mm²
AWG Conductor Section24 ... 12
Flexible conductor section with toe cap, without plastic sleeve0.25 mm² ... 2.5 mm²
Flexible conductor section with toe cap, with plastic sleeve0.25 mm² ... 2.5 mm²
2 conductors with the same cross-section, flexible with TWIN toe cap with plastic sleeve0.5 mm² ... 1.5 mm²
Male gauge a x b / Diameter2.8 mm x 2.0 mm / 2.0 mm
Peel Length10 mm
Facts about toe caps without an insulated collar
Recommended crimp pliers1212034 CRIMPFOX 6
toe caps without insulating collar, according to DIN 46228-1Cross-section: 0.5 mm²; Length: 8 mm ... 10 mm
Cross-section: 0.75 mm²; Length: 8 mm ... 10 mm
Cross-section: 1 mm²; Length: 8 mm ... 10 mm
Cross-section: 1.5 mm²; Length: 8 mm ... 10 mm
Cross-section: 2.5 mm²; Length: 10 mm
Facts about Insulated Collar Toe Caps
Recommended crimp pliers1212034 CRIMPFOX 6
toe caps with insulated collar, according to DIN 46228-4Cross-section: 0.5 mm²; Length: 8 mm ... 10 mm
Cross-section: 0.75 mm²; Length: 8 mm ... 10 mm
Cross-section: 1 mm²; Length: 8 mm ... 10 mm
Cross-section: 1.5 mm²; Length: 8 mm ... 10 mm
Cross-section: 2.5 mm²; Length: 10 mm
Material Data
Material data - contact
ObservationWEEE/RoHS compliant, filament-free according to IEC 60068-2-82/JEDEC JESD 201
Contact materialCu Alloy
Surface CharacteristicsMalleable cast iron tinning
Metal surface of the terminal point (top layer)Tin (4 - 8 μm Sn)
Metal surface contact area (top layer)Tin (4 - 8 μm Sn)
Material data - housing
Color (Housing)Green (6021)
Insulating materialPA
Insulating material groupI
CTI according to IEC 60112600
Flammability class according to UL 94V0
Flammability number of GWFI incandescent filaments according to EN 60695-2-12850
Ignition temperature of incandescent filaments GWIT according to EN 60695-2-13775
Ball hardness test temperature according to EN 60695-10-2125 °C
Material data: drive element
Color (Drive Element)Orange (2003)
Insulating materialPBT
Insulating material groupI
CTI according to IEC 60112600
Flammability class according to UL 94V0
Dimensions
Dimension Schemeedyvovzxrs.jpg
Step5.08 mm
Width [w]25.34 mm
Height [h]15 mm
Length [l]25.73 mm
assembly
bridle
Tightening torque0.3 Nm
Notes
Observation regarding the operationAccording to DIN EN 61984, COMBICON connectors are connectors without switching power (COC). In the event of use as prescribed, they must not be plugged in or unplugged under voltage or under load.
Mechanical testing
Connecting Conductors
Test SpecificationDIN EN 60999-1 (VDE 0609-1):2000-12
ResultApproved Test
Checking for damage to conductors and loosening
Test SpecificationDIN EN 60999-1 (VDE 0609-1):2000-12
ResultApproved Test
Repeated connection and disconnection
Test SpecificationDIN EN 60999-1 (VDE 0609-1):2000-12
ResultApproved Test
Tensile Test
Test SpecificationDIN EN 60999-1 (VDE 0609-1):2000-12
Conductor Section/Conductor Type/Tensile Force Nominal Value/Actual Value0.2 mm² / rigid / > 10 N
0.2 mm² / flexible / > 10 N
2.5 mm² / rigid / > 50 N
2.5 mm² / flexible / > 50 N
Forces when plugging in and unplugging
Test SpecificationDIN EN 60512-13-2:2006-11
ResultApproved Test
Number of cycles25
Plug-in force approx.8 N
Power when unplugging by pole approx.6 N
Resistance of the signs
Test SpecificationDIN EN 60068-2-70:1996-07
ResultApproved Test
Polarization & Coding
Test SpecificationDIN EN 60512-13-5:2006-11
ResultApproved Test
Eye Exam
Test SpecificationDIN EN 60512-1-1:2003-01
ResultApproved Test
Dimensional Examination
Test SpecificationDIN EN 60512-1-2:2003-01
ResultApproved Test
Environmental and life-life conditions
Vibration test
Test SpecificationDIN EN 60068-2-6 (VDE 0468-2-6):2008-10
frequency10 - 150 - 10 Hz
Sweep speed1 octave/min
Amplitude0.35 mm (10 Hz ... 60.1 Hz)
Acceleration5g (60.1 Hz ... 150 Hz)
Test duration per axis2.5 h
Test DirectionsX, Y, and Z axes
Durability Test
Test SpecificationDIN EN 60512-9-1 (VDE 0687-512-9-1):2010-12
Bearable shock voltage at sea level4.8 kV
Contact Resistance R11 mΩ
Contact Resistance R21 mΩ
Plug Cycles25
Insulation Resistance Adjacent Poles> 5 MΩ
Climate Essay
Test SpecificationDIN EN ISO 6988:1997-03
Corrosion fatigue0.2 dm3UNDER2in 300 dm3/40 °C/1 cycle
Thermal stress105 °C/168 h
Bearable AC voltage2.21 kV
Crash
Test SpecificationDIN EN 60068-2-27 (VDE 0468-2-27):2010-02
Shock TypeSemi-sinusoidal
Acceleration30g
Duration of the crash18 ms
Test DirectionsX, Y, and Z axes (pos. and neg.)
Environmental conditions
Ambient Temperature (Service)-40 °C ... 100 °C (depending on the rating curve)
Ambient Temperature (Storage/Transport)-40 °C ... 70 °C
Relative humidity of the air (storage/transport)30 % ... 70 %
Ambient Temperature (Mounting)-5 °C ... 100 °C
Electrical Testing
Thermal Test Test Group C
Test SpecificationDIN EN 60512-5-1:2003-01
Number of poles tested24
Insulation resistance
Test SpecificationDIN EN 60512-3-1:2003-01
Insulation Resistance Adjacent Poles> 5 MΩ
Temperature Cycles
Test SpecificationDIN EN 60999-1 (VDE 0609-1):2000-12
ResultApproved Test
Creepage Lines & Air Isolation Distances
Test SpecificationDIN EN 60664-1 (VDE 0110-1):2008-01
Insulating material groupI
Resistance to leakage currents (DIN EN 60112 (VDE 0303-11))CTI 600
Sizing Insulation Voltage (III/3)320 V
Nominal transient voltage (III/3)4 kV
minimum value of air insulation distance - non-homogeneous field (III/3)3 mm
Minimum creepage line value (III/3)4 mm
Sizing Insulation Voltage (III/2)320 V
Nominal transient voltage (III/2)4 kV
Minimum Value of Air Insulation Distance - Non-Homogeneous Field (III/2)3 mm
Minimum creepage line value (III/2)3 mm
Sizing Insulation Voltage (II/2)630 V
Nominal transient voltage (II/2)4 kV
Minimum Value of Air Insulation Distance - Non-Homogeneous Field (II/2)3 mm
Minimum creepage line value (II/2)3.2 mm
Packaging Information
Type of packagingBoxed Packaging

ETIM for 1107074 Connectors (EC002638)
Feature Name Feature Value
Type of connection (EF000064) Other
Contact type (EF001587) Bus
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 5.08 mm
Modular spacing connections (EF006827) 5.08 mm
Angle contact/conductor connection (EF007546) Other
Rated current In (EF008250) 12 A
Rated voltage (EF000228) 320 V
Rated surge voltage (EF002993) 4 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Connectable conductor cross section fine-strand without cable end sleeve (EF007341) 0.2 mm²
Connectable conductor cross section fine-strand with cable end sleeve (EF007339) 0.25 mm²
Connectable conductor cross section solid-core (EF007337) 0.2 mm²
Type of electric connection (EF003961) Spring clamp connection
Connectable cable type (EF006816) Tubular cable
Material of contact surface (EF004020) Tin
Material contact (EF007544) Copper
Material insulation body (EF007543) Polyamide (PA)
Housing material (EF001596) Other
Housing colour (EF000136) Green
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
