PHOENIX CONTACT FK-MPT 0,5/ 5-3,5 GY LCBK FK-MPT 0,5/ 5-3,5 GY LCBK 1742004 PHOENIX CONTACT PCB terminal block View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FK-MPT 0,5/ 5-3,5 GY LCBK 1742004 PHOENIX CONTACT PCB terminal block

FK-MPT 0,5/ 5-3,5 GY LCBK

1742004

PHOENIX CONTACT

50 Pcs.

PCB terminal block Terminal block for printed circuit board, nominal current: 4 A, dimensioning voltage (III/2): 250 V, nominal section: 0.5 mm², number of potentials: 5, number of rows: 1, number of poles per row: 5, family of articles: FK-MPT 0.5/.. -V, pitch: 3.5 mm, connection type: Push-in spring connection, mounting: Wave soldering, conductor connection direction/printed circuit board: 90 °, color: gray, Pin arrangement: Linear pin arrangement, Pin length [P]: 3.5 mm, number of solder pins per potential: 1, packaging type: boxed

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1742004
Packing unit50 pc
Minimum order quantity50 pc
NoteMade to Order (non-returnable)
GTIN4046356294973
Weight per Piece (excluding packing)1.710 g
Custom tariff number85369010
Country of originDE (Germany)

Dimensions

Length [ l ]7 mm
Pitch3.5 mm
Dimension a14 mm
Width [ w ]18 mm
Height9.5 mm
Height [ h ]13 mm
Solder pin [P]3.5 mm
Pin spacing3.5 mm
Hole diameter1 mm

General

Range of articlesFK-MPT 0,5/..-V
Rated surge voltage (III/3)2.5 kV
Rated surge voltage (III/2)2.5 kV
Rated surge voltage (II/2)2.5 kV
Rated voltage (III/3)160 V
Rated voltage (III/2)250 V
Rated voltage (II/2)250 V
Connection in acc. with standardEN-VDE
Nominal current IN4 A
Nominal cross section0.5 mm²
Solder pin surface
Stripping length6.5 mm
Number of positions5

Connection data

Conductor cross section AWG min.26
Conductor cross section AWG max.20

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values

Classifications
