PHOENIX CONTACT FK-MPT 0,5/ 4-ICVA-3,5 GN R56 FK-MPT 0,5/ 4-ICVA-3,5 GN R56 1726240 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FK-MPT 0,5/ 4-ICVA-3,5 GN R56 1726240 PHOENIX CONTACT Printed-circuit board connector

FK-MPT 0,5/ 4-ICVA-3,5 GN R56

1726240

PHOENIX CONTACT

300 Pcs.

Printed-circuit board connector Printed circuit board base housing, nominal section: 0.5 mm², color: green, nominal current: 3 A, dimensioning voltage (III/2): 250 V, contact surface: Tin, contact type: Female connection, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, family of articles: FK-MPT 0.5/.. -ICVA, pitch: 3.5 mm, mounting: Weld THR, pin arrangement: Linear pin arrangement, pin length [P]: 3.4 mm, number of welding pins per potential: 1, plug-in system: COMBICON COMPACT FK-MPT - IC, Plug-in face orientation: Standard, Lock: without, fixing type: without, packaging type: 56 mm wide strap, The base strip protected against casual contacts, serves for the FK-MPT 0.5 card terminal holder Printed circuit board base housing, nominal section: 0.5 mm2, color: green, nominal current: 3 A, nominal voltage (III/2): 250 V, contact surface: Sn, contact connection type: Female, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, family of articles: FK-MPT 0.5/..

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey1726240
Packing unit300 pc
Minimum order quantity300 pc
GTIN4046356133180
Weight per Piece (excluding packing)2.890 g
Custom tariff number85366930
Country of originDE (Germany)

Dimensions

Length [ l ]9.1 mm
Width16.5 mm
Pitch3.5 mm
Dimension a10.5 mm
Width [ w ]16.5 mm
Height [ h ]12.2 mm
Height8.8 mm
Length of the solder pin3.4 mm
Pin dimensions0.3 x 0.9 mm
Length9.1 mm

General

Range of articlesFK-MPT 0,5/..-ICVA
Insulating material groupIIIa
Rated surge voltage (III/3)2.5 kV
Rated surge voltage (III/2)2.5 kV
Rated surge voltage (II/2)2.5 kV
Rated voltage (III/3)160 V
Rated voltage (III/2)250 V
Rated voltage (II/2)250 V
Connection in acc. with standardEN-VDE
Nominal current IN3 A
Insulating materialPA
Flammability rating according to UL 94V0
Colorgreen
Number of positions4

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
