PHOENIX CONTACT FC 4-PCB/4 FC 4-PCB/4 1074462 PHOENIX CONTACT PCB header, 4-pos. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FC 4-PCB/4 1074462 PHOENIX CONTACT PCB header, 4-pos.

FC 4-PCB/4

1074462

PHOENIX CONTACT

10 Pcs.

PCB header, 4-pos. Base housing with printed circuit board, 4 poles

Automation > Endplate and partition plate for terminal block
Enclosures connectivity

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Technical data
Product properties
Product typePlug
Number of positions4
Number of rows1
Potentials4
Insulation characteristics
Overvoltage categoryIII
Degree of pollution3
Electrical properties
Rated surge voltage4 kV
Maximum power dissipation for nominal condition0.77 W
Connection data
Nominal cross section2.5 mm²
Rated cross section AWG14
Level 1
Connection in acc. with standardIEC 61984
Conductor cross section rigid0.5 mm² ... 2.5 mm²
Cross section AWG20 ... 14 (converted acc. to IEC)
Conductor cross section flexible0.5 mm² ... 2.5 mm²
Conductor cross section, flexible [AWG]20 ... 14 (converted acc. to IEC)
Nominal current15 A
Maximum load current15 A
Nominal voltage320 V
Dimensions
Width41.1 mm
Height29.1 mm
Depth34.3 mm
Material specifications
Colorgray (RAL 7042)
Flammability rating according to UL 94V0
Insulating material groupI
Insulating materialPA
Static insulating material application in cold-60 °C
Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21))130 °C
Relative insulation material temperature index (Elec., UL 746 B)130 °C
Fire protection for rail vehicles (DIN EN 45545-2) R22HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R23HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R24HL 1 - HL 3
Fire protection for rail vehicles (DIN EN 45545-2) R26HL 1 - HL 3
Calorimetric heat release NFPA 130 (ASTM E 1354)28 MJ/kg
Surface flammability NFPA 130 (ASTM E 162)passed
Specific optical density of smoke NFPA 130 (ASTM E 662)passed
Smoke gas toxicity NFPA 130 (SMP 800C)passed
Electrical tests
Short-time withstand current 2.5 mm²0.01 kA
ResultTest passed
Mechanical properties
Mechanical data
Open side panelNo
Environmental and real-life conditions
Service life
Insertion/withdrawal cycles100
Needle-flame test
Time of exposure30 s
ResultTest passed
Oscillation/broadband noise
SpecificationDIN EN 60255-21-1:1996-05 (following)
Frequency10 Hz ... 150 Hz
Acceleration1g (84.2 Hz ... 150 Hz)
Test directionsX-, Y- and Z-axis
ResultTest passed
Shocks
SpecificationDIN EN 60255-21-1:1996-05 (following)
Pulse shapeHalf-sine
Acceleration30g
Shock duration11 ms
Number of shocks per direction3
Test directionsX-, Y- and Z-axis (pos. and neg.)
ResultTest passed
Ambient conditions
Ambient temperature (operation)-60 °C ... 105 °C (max. short-term operating temperature RTI Elec.)
Ambient temperature (storage/transport)-25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C)
Ambient temperature (assembly)-5 °C ... 70 °C
Ambient temperature (actuation)-5 °C ... 70 °C
Permissible humidity (storage/transport)30 % ... 70 %
Standards and regulations
Connection in acc. with standardIEC 61984
Mounting
Mounting typePCB mounting

ETIM for 1074462 Terminal blocks (EC000886)
Feature Name Feature Value
Colour (EF000007) Grey
Thickness (EF000125) 41.1 mm
Inflammability class of insulation material according to UL94 (EF002521) V0

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
