PST 1,0/10-3,5 RD 1704328 PHOENIX CONTACT Pin strip
PST 1,0/10-3,5 RD
1704328
PHOENIX CONTACT
50 Pcs.
Pin strip
Male connector, nominal section: 0.5 mm², color: red, nominal current: 8 A (Depending on the connector used), dimensioning voltage (III/2): 250 V, contact surface: Tin, contact type: Male, Number of potentials: 10, Number of definitions: 1, Number of poles per row: 10, number of connections: 10, family of articles: PST 1.0/.. -V, pitch: 3.5 mm, mounting: Solder THR, pin arrangement: Linear pin arrangement, pin length [P]: 3.8 mm, Stecksystem: COMBICON COMPACT PST 1, Lock: without, packaging type: boxed packaging, The maximum current depends on the connector used. Of the two current values, the lower value for the connector and the male connector is decisive. The plug is made of high-temperature resistant plastic, which makes it suitable for the reflow soldering process.
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Dimensions
| Pitch | 3.5 mm |
|---|---|
| Dimension a | 31.5 mm |
| Height | 9.5 mm |
| Length of the solder pin | 3.5 mm |
| Pin dimensions | ø 1 mm |
General
| Range of articles | PST 1,0/..-V |
|---|---|
| Rated voltage (III/3) | 160 V |
| Connection in acc. with standard | EN-VDE |
| Nominal current IN | 8 A |
| Color | red |
| Number of positions | 10 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
