View larger
Images are for illustrative purposes only. Please refer to data sheet for details
DFK-MSTBVA 2,5/ 4-G-5,08 BK 1715755 PHOENIX CONTACT Printed-circuit board connector
DFK-MSTBVA 2,5/ 4-G-5,08 BK
1715755
PHOENIX CONTACT
50 Pcs.
Printed-circuit board connector
Wall pass-through housing, nominal section: 2.5 mm², color: black, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, family of articles: DFK-MSTBVA 2.5/.. -G, pitch: 5.08 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.9 mm, number of solder pins per potential: 1, plug-in system: COMBICON MSTB 2.5, Plug-in face orientation: Standard, locking: without, fixing type: without, packaging type: boxed
Connectors > Printed circuit board connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Feed-through header, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 4, pitch: 5.08 mm, color: black, contact surface: Tin, mounting: Wave soldering
Key Commercial Data
| Orderkey | 1715755 |
|---|---|
| Packing unit | 1 |
| GTIN | 4055626481968 |
| Custom tariff number | 85366930 |
Dimensions
| Length [ l ] | 12 mm |
|---|---|
| Pitch | 5.08 mm |
| Dimension a | 15.24 mm |
| Height | 19 mm |
| Length of the solder pin | 3.9 mm |
| Length | 12 mm |
General
| Range of articles | DFK-MSTBVA 2,5/..-G |
|---|---|
| Color | black |
| Number of positions | 4 |
Environmental Product Compliance
| China RoHS | Environmentally friendly use period: unlimited = EFUP-e |
|---|---|
| No hazardous substances above threshold values |
Classifications
eCl@ss
| eCl@ss 5.1 | 27260700 |
|---|---|
| eCl@ss 6.0 | 27260700 |
| eCl@ss 7.0 | 27440402 |
| eCl@ss 8.0 | 27440402 |
| eCl@ss 9.0 | 27440402 |
ETIM
| ETIM 5.0 | EC002637 |
|---|---|
| ETIM 6.0 | EC002637 |
| ETIM 7.0 | EC002637 |
