PHOENIX CONTACT BCVP-508R- 2 GY BCVP-508R- 2 GY 5438171 PHOENIX CONTACT Part plug,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º po.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

BCVP-508R- 2 GY 5438171 PHOENIX CONTACT Part plug,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º po..

BCVP-508R- 2 GY

5438171

PHOENIX CONTACT

100 Pcs.

Part plug,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º poles: 2,Pitch: 5,08 mm,the Technique of connection: Connection by screw with capsule-traction,Color: gray signs,contact Surface: Tin

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Commercial data

Ordering code5438171
Pieces/pack50 PCS
Sales keyAAYBAA -
Minimum order quantity100 PCS
GTIN4046356469135
Weight per piece (excluding packaging)4,548 g
Customs Tariff number85366990
Country of originDE (Germany)

dimensions

Length [L]12.52 mm
Width [W]10.36 mm
Height [h]26.03 mm
Step5.08 mm
Measure A5.08 mm

generality

Article familyBCVP-R
No. of poles2
LinkScrew connection with cage
Insulation Material GroupThe
Sizing impulse voltage (III/3)4 kV
Sizing Impulse Voltage (III/2)4 kV
Sizing Impulse Voltage (II/2)4 kV
Sizing voltage (III/3)250 V
Sizing voltage (III/2)320 V
Sizing voltage (II/2)630 V
Rated Current IN12 A
Nominal cross-section2.5 mm²
Maximum load current12 A (with a conductor cross-section of 2.5 mm²)
Insulation materialPA
Combustibility class according to UL 94V0
Stripping length7 mm
ThreadM3
Torque min.0.5 Nm
Max. torque0.6 Nm

Connection data

Rigid conductor cross-section min.0.2 mm²
Solid conductor cross-section max.2.5 mm²
Flexible conductor cross-section min.0.2 mm²
Flexible conductor cross-section max.2.5 mm²
Flexible conductor cross-section with cable lug without plastic collar min.0.25 mm²
Flexible conductor cross-section with cable lug without plastic collar max.2.5 mm²
Flexible conductor cross-section with cable lug with plastic collar min.0.25 mm²
Flexible conductor cross-section with cable lug with plastic collar max.2.5 mm²
Conductor cross-section AWG min.24
Conductor cross-section AWG max.12
2 conductors same diameter, rigid min.0.2 mm²
2 conductors same diameter, rigid max.1 mm²
2 conductors same diameter, flexible min.0.2 mm²
2 conductors same diameter, flexible max.1.5 mm²
2 conductors with the same diameter, flexible with AEH without plastic collar min.0.25 mm²
2 conductors with the same diameter, flexible with AEH without plastic collar max.1 mm²
2 conductors with the same diameter, flexible with TWIN-AEH with plastic collar min.0.5 mm²
2 conductors with the same diameter, flexible with TWIN-AEH with plastic collar max.1.5 mm²

Regulations and requirements

Standard-compliant connectionCUL
Combustibility class according to UL 94V0

Environmental Product Compliance

REACh SVHCLead 7439-92-1
China RoHSEnvironmentally Friendly Intended Use Period (EFUP): 50 years
Information on hazardous substances can be found in the manufacturer's declaration under "Downloads"
