View larger
Images are for illustrative purposes only. Please refer to data sheet for details
BCP-500- 3 GN 5448242 PHOENIX CONTACT Part plug,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º pole..
BCP-500-3 GN
5448242
PHOENIX CONTACT
100 Pcs.
Part plug,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º poles: 3,Pitch: 5 mm,Technique of connection: Connection by screw with capsule-traction,Color: whitish green,contact Surface: Tin
Connector for printed circuit board, nominal section: 2.5 mm², color: off-white green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Female, number of potentials: 3, number of rows: 1, number of poles: 3, number of connections: 3, article family: BCP, pitch: 5 mm, connection type: Screw connection with traction capsule, screw clamping form: L Longitudinal slot, conductor connection direction/printed circuit board: 0 °, clamping hook: - Clamping hook, plug-in system: BASICLINE 2.5, locking: without, fixing type: without, packaging type: packed in box
Cables > Cable connector
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Commercial data
| The code for the order | Five million four hundred forty eight thousand two hundred forty two |
|---|---|
| Pieces/pack. | 100 PCS |
| Sales key | AAYBAA - |
| The amount of minimum order | 100 PCS |
| GTIN | Four trillion forty six billion three hundred fifty six million eight hundred twenty seven thousand nine hundred four |
| Weight per piece (package included) | 4,850 g |
| Number customs tariff | Eighty five million three hundred sixty six thousand nine hundred ninety |
| Country of origin | CN (China) |
General
| Family article | BCP |
|---|---|
| N. of poles | Three |
| Link | Screw connection with cage |
| Group insulating material | The |
| Surge voltage strength (III/3) | 4 kV |
| Surge voltage strength (III/2) | 4 kV |
| Surge voltage strength (II/2) | 4 kV |
| Rating voltage (III/3) | 250 V |
| Rating voltage (III/2) | 320 V |
| Rating voltage (II/2) | 630 V |
| Attack in accordance with | EN-VDE |
| Rated current IN | 12 To |
| Nominal section | 2.5 mm2 |
| Maximum load current | 12 A (with a conductor cross section of 2.5 mm2) |
| Insulating material | PA |
| Class behaviour according to UL 94 | V0 |
| Stripping length | 7 mm |
| Thread | M3 |
| Torque min. | 0.4 Nm |
| Torque, max. | 0.5 Nm |
Data link
| Conductor cross section, rigid min. | 0.2 mm2 |
|---|---|
| Conductor cross section, rigid max. | 2.5 mm2 |
| Conductor cross section flexible min. | 0.2 mm2 |
| Conductor cross section flexible max. | 2.5 mm2 |
| Conductor cross section flexible with crimp connector without collar plastic min. | 0.25 mm2 |
| Conductor cross section flexible with crimp connector without collar plastic max. | 2.5 mm2 |
| Conductor cross section flexible with aeh with collar plastic min. | 0.25 mm2 |
| Conductor cross section flexible with aeh with collar plastic max. | 2.5 mm2 |
| Cross section conductor AWG min. | Twenty four |
| Cross section conductor AWG max. | Twelve |
| 2 conductors with the same diameter, rigid min. | 0.2 mm2 |
| 2 conductors with the same diameter, rigid max. | 1 mm2 |
| 2 conductors with the same diameter, flexible, min. | 0.2 mm2 |
| 2 conductors with the same diameter, flexible, max. | 1.5 mm2 |
| 2 conductors with the same diameter, flexible with AEH without collar plastic min. | 0.25 mm2 |
| 2 conductors with the same diameter, flexible with AEH without collar plastic max. | 1 mm2 |
| 2 conductors with the same diameter, flexible with TWIN-AEH with collar plastic min. | 0.5 mm2 |
| 2 conductors with the same diameter, flexible with TWIN-AEH with collar plastic max. | 1.5 mm2 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Period of use conforms to the target without damage to the environment (EFUP): 50 years |
| The information on hazardous substances found in the declaration of the manufacturer under "Downlaods" |
Rankings
eCl@ss 4.0272607xxeCl@ss 4.1Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.0Twenty seven million two hundred sixty thousand seven hundred oneeCl@ss 5.1Twenty seven million two hundred sixty thousand seven hundredeCl@ss 6.0Twenty seven million two hundred sixty thousand seven hundredeCl@ss 7.0Twenty seven million four hundred forty thousand three hundred nineeCl@ss 8.0Twenty seven million four hundred forty thousand three hundred nineeCl@ss 9.0Twenty seven million four hundred forty thousand three hundred nine
UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred oneUNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 11Thirty nine million one hundred twenty one thousand four hundred thirty twoUNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred nine
| Feature Name | Feature Value |
|---|---|
| Type of connection (EF000064) | Other |
| Contact type (EF001587) | Bus |
| Number of poles (EF001391) | 3 |
| Number of plug-in contact rows (EF006935) | 1 |
| Modular spacing contacts (EF007326) | 5 mm |
| Modular spacing connections (EF006827) | 5 mm |
| Angle contact/conductor connection (EF007546) | Other |
| Rated current In (EF008250) | 12 A |
| Rated voltage (EF000228) | 320 V |
| Rated surge voltage (EF002993) | 4 kV |
| Over voltage category (EF006785) | III |
| Pollution degree (EF006786) | 2 |
| Connectable conductor cross section fine-strand without cable end sleeve (EF007341) | 0.2 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve (EF007339) | 0.25 mm² |
| Connectable conductor cross section solid-core (EF007337) | 0.2 mm² |
| Type of electric connection (EF003961) | Screw connection |
| Connectable cable type (EF006816) | Tubular cable |
| Material of contact surface (EF004020) | Tin |
| Material contact (EF007544) | Copper |
| Material insulation body (EF007543) | Polyamide (PA) |
| Housing material (EF001596) | Other |
| Housing colour (EF000136) | Other |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Operating temperature (EF002393) | -40 °C |
