PHOENIX CONTACT BCP-381-3 GN BD:1-3 BCP-381- 3 GN BD:1-3 5455756 PHOENIX CONTACT Part plug, nominal Current: 8 A, Technique of connection: Conne.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

BCP-381- 3 GN BD:1-3 5455756 PHOENIX CONTACT Part plug, nominal Current: 8 A, Technique of connection: Conne..

BCP-381-3 GN BD:1-3

5455756

PHOENIX CONTACT

100 Pcs.

Part plug, nominal Current: 8 A, Technique of connection: Connection by screw with capsule-traction, Color: whitish green, contact Surface: Tin Connector for printed circuit board, nominal cross-section: 1.5 mm², color: off-white green, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Female, number of potentials: 3, number of rows: 1, number of poles: 3, number of connections: 3, article family: BCP, pitch: 3.81 mm, connection type: Screw connection with traction capsule, screw clamping form: L Longitudinal slot, conductor/printed circuit board connection direction: 0 °, plug-in system: BASICLINE 1.5, lock: without, fixing type: without, packaging type: boxed

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Data commercial

Key orderFive million four hundred fifty five thousand seven hundred fifty six
Packing unit100 pcs
Key sellingAAYCAA -
Minimum order quantity100 pcs
EANFour trillion forty six billion three hundred fifty six million nine hundred ninety six thousand three hundred forty one
Unit weight (excluding packaging)2,000 g
Tariff number tariffEighty five million three hundred sixty six thousand nine hundred ninety
Country of originCN (China)

Dimensions

Length [ l ]16,1 mm
Width [ w ]12,22 mm
Height [ h ]11,1 mm
Step3,81 mm
Average7.62 mm

Overview

Family of articlesBCP
Number of polesThree
Type of connectionConnection by screw with capsule-traction
Tension and sizing (III/3)160 V
Connection according to standardEN-VDE
Nominal current IN8 To
Nominal cross section1.5 mm2

Data connection

Core cross-section rigid min.0,2 mm2
Section of conductor rigid max.1.5 mm2
Section of flexible conductor, min.0,2 mm2
Section of flexible conductor max.1.5 mm2
Section of flexible conductor with toe cap, without plastic sleeve min.0.25 mm2
Section of flexible conductor with toe cap, without plastic sleeve max.1.5 mm2
Section of flexible conductor with toe, with plastic sleeve min.0.25 mm2
Section of flexible conductor with toe, with plastic sleeve max.0.5 mm2
Section of conductor AWG min.Twenty four
Section of conductor AWG max.Sixteen
2 conductors with same cross section, rigid min.0,2 mm2
2 conductors with same cross section, rigid max.0.5 mm2
2 conductors with same cross section, flexible, min.0.25 mm2
2 conductors with same cross section, flexible max.0.75 mm2
2 conductors with same cross section, flexible with AEH without plastic sleeve min.0.25 mm2
2 conductors with same cross section, flexible with AEH without plastic sleeve max.0,34 mm2
2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve min.0.5 mm2
2 conductors with same cross section, flexible with TWIN-AEH with plastic sleeve max.0.5 mm2

Standards and specifications

Connection according to standardEN-VDE

Environmental Product Compliance

REACh SVHCLead 7439-92-1
China RoHSSpace of time for the intended use (FEUP): 50 years
You will find information about hazardous substances in the manufacturer's declaration in the "Downloads"tab
