PHOENIX CONTACT BCP-350- 2 GY BD:15-16 BCP-350- 2 GY BD:15-16 5454171 PHOENIX CONTACT Part plug, nominal Current: 8 A, Technique of connection: Con.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

BCP-350- 2 GY BD:15-16 5454171 PHOENIX CONTACT Part plug, nominal Current: 8 A, Technique of connection: Con..

BCP-350- 2 GY BD:15-16

5454171

PHOENIX CONTACT

100 Pcs.

Part plug, nominal Current: 8 A, Technique of connection: Connection by screw with capsule-traction, Color: gray signs, contact Surface: Tin

Cables > Cable connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Commercial data

Order key5454171
Packaging unit100 pcs
Sell keyAAYCAA -
Minimum Order Quantity100 pcs
Ean4046356948777
Weight per unit (excluding packaging)1,500 g
Tariff rate number85366990
Country of originCN (China)

Dimensions

Length [ l ]16.1 mm
Width [ w ]7.7 mm
Height [ h ]11.1 mm
Step3.5 mm
Medium to3.5 mm

General

Article FamilyBCP
Number of poles2
Connection typeScrew connection with traction capsule
Sizing voltage (III/3)160 V
Standard-compliant connectionEN-VDE
Nominal Current IN8 A
Nominal Section1.5 mm²

Connection data

Rigid conductor section min.0.2 mm²
Max. rigid conductor section1.5 mm²
Flexible conductor section min.0.2 mm²
Max. flexible conductor section1.5 mm²
Flexible conductor section with toe cap, without min plastic sleeve.0.25 mm²
Flexible conductor section with toe cap, without plastic sleeve max.1.5 mm²
Flexible conductor section with tip, with min plastic sleeve.0.25 mm²
Flexible conductor section with ferrule, with plastic sleeve max.0.5 mm²
Conductor section AWG min.24
Conductor section AWG max.16
2 conductors with the same cross-section, rigid min.0.2 mm²
2 conductors with the same cross-section, rigid max.0.5 mm²
2 conductors with the same cross-section, flexible min.0.25 mm²
2 conductors with the same cross-section, flexible max.0.75 mm²
2 conductors with the same cross-section, flexible with HAE, without min plastic sleeve.0.25 mm²
2 conductors with the same cross-section, flexible with HAE without plastic sleeve max.0.34 mm²
2 conductors with the same cross-section, flexible with TWIN-AEH, with min plastic sleeve.0.5 mm²
2 conductors with the same cross-section, flexible with TWIN-HAE with plastic sleeve max.0.5 mm²

Standards & Specifications

Standard-compliant connectionEN-VDE

Environmental Product Compliance

REACh SVHCLead 7439-92-1
China RoHSTime Span for Intended Use (EFUP): 50 years
You can find information about hazardous substances in the manufacturer's declaration under the "Downloads" tab
