PHOENIX CONTACT BCH-508VS-4 BK BCH-508VS- 4 BK 5452155 PHOENIX CONTACT Housing base,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

BCH-508VS- 4 BK 5452155 PHOENIX CONTACT Housing base,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º..

BCH-508VS-4 BK

5452155

PHOENIX CONTACT

100 Pcs.

Housing base,nominal Current: 12 A,rated Voltage (III/2): 320 V,N. º poles: 4,Pitch: 5,08 mm,Color: black,contact Surface: Tin,Assembly: wave Soldering Printed circuit board base housing, nominal section: 2.5 mm², color: black, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact type: Male, number of potentials: 4, number of rows: 1, number of poles: 4, number of connections: 4, family of articles: BCH-VS, pitch: 5.08 mm, mounting: Wave soldering, Pin arrangement: Linear pin arrangement, pin length [P]: 3.9 mm, number of solder pins per potential: 1, plug-in system: BASICLINE 2.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Commercial data

The code for the orderFive million four hundred fifty two thousand one hundred fifty five
Pieces/pack.100 PCS
Sales keyAAYBHA -
The amount of minimum order100 PCS
GTINFour trillion forty six billion three hundred fifty six million eight hundred fifty four thousand two hundred sixty nine
Weight per piece (package included)1,520 g
Number customs tariffEighty five million three hundred sixty six thousand nine hundred ninety

Size

Length [ l ]8.6 mm
Width22,32 mm
Step5.08 mm
Measure15,24 mm
Width [ w ]22,32 mm
Height [ h ]15.9 mm
Mounting height12 mm
Pin length solder3.9 mm
The size of the shanks1 x 1 mm
Length8.6 mm

General

Family articleBCH-VS
Group insulating materialThe
Surge voltage strength (III/3)4 kV
Surge voltage strength (III/2)4 kV
Surge voltage strength (II/2)4 kV
Rating voltage (III/3)250 V
Rating voltage (III/2)320 V
Rating voltage (II/2)400 V
Attack in accordance withEN-VDE
Rated current IN12 To
Maximum load current12 To
Insulating materialPA
Class behaviour according to UL 94V0
Colorblack
N. of polesFour

Regulations and requirements

Attack in accordance withEN-VDE
CUL
Class behaviour according to UL 94V0

Environmental Product Compliance

China RoHSPeriod for proper use: unlimited = EFUP-and
Any hazardous substances above the threshold values

Rankings


ETIM for 5452155 Connectors (EC002637)
Feature Name Feature Value
Connector model (EF007495) Fixed connector
Contact type (EF001587) Pin
Number of poles (EF001391) 4
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 5.08 mm
Modular spacing connections (EF006827) 5.08 mm
Rated current In (EF008250) 12 A
Rated voltage (EF000228) 320 V
Rated surge voltage (EF002993) 4 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Material of contact surface (EF004020) Tin
Type of electric connection (EF003961) Other
Diameter connection pin (EF006823) 1.4 mm
Length pin (EF006825) 3.9 mm
Material insulation body (EF007543) Other
Housing colour (EF000136) Black
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
Type of fastening (EF002442) Other
Type of banding (EF007011) Carton (for SMD)

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
