PHOENIX CONTACT BCH-508H-8 GN BCH-508H- 8 GN 5446370 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

BCH-508H- 8 GN 5446370 PHOENIX CONTACT Printed-circuit board connector

BCH-508H-8 GN

5446370

PHOENIX CONTACT

100 Pcs.

Printed-circuit board connector Printed circuit board base housing, nominal section: 2.5 mm², color: whitish green, nominal current: 12 A, nominal voltage (III/2): 320 V, contact surface: Tin, contact connection type: Male, number of potentials: 8, number of rows: 1, number of poles: 8, number of connections: 8, article family: BCH-H, pitch: 5.08 mm, mounting: Wave soldering, pin arrangement: Linear pin arrangement, pin length [P]: 3.5 mm, number of solder pins per potential: 1, plug-in system: BASICLINE 2.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed PCB headers, nominal current: 12 A, rated voltage (III/2): 320 V, nominal cross section: 1.5 mm², number of positions: 8, pitch: 5.08 mm, color: pastel green, contact surface: Tin, mounting: Wave soldering, pin layout: Linear pinning, solder pin [P]: 3.5 mm

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Data commercial

Key orderFive million four hundred forty six thousand three hundred seventy
Packing unit100 pcs
Key sellingAAYBFA -
Minimum order quantity100 pcs
EANFour trillion forty six billion three hundred fifty six million eight hundred thirty two thousand eight hundred ninety two
Unit weight (excluding packaging)2,927 g
Tariff number tariffEighty five million three hundred sixty six thousand nine hundred ninety
Country of originCN (China)

Drawings

Esquema de dimensiones

Outline dimensions

Back to top

Dimensions

Length [ l ]12 mm
Width40,64 mm
Step5,08 mm
Average35,56 mm
Width [ w ]40,64 mm
Height [ h ]12,1 mm
Height of construction8.6 mm
Length of the pin welding3.5 mm
Dimensions of pin1 x 1 mm
Length12 mm
Back to top

Overview

Family of articlesBCH-H
Group insulating materialI
Transient voltage design (III/3)4 kV
Transient voltage design (III/2)4 kV
Transient voltage design (II/2)4 kV
Tension and sizing (III/3)250 V
Tension and sizing (III/2)320 V
Tension and sizing (II/2)400 V
Connection according to standardEN-VDE
Nominal current IN12 To
Maximum load current12 To
IsolationPA
Class of flammability according to UL 94V0
Colorwhitish green
Number of polesEight
Back to top

Standards and specifications

Connection according to standardEN-VDE
CUL
Class of flammability according to UL 94V0
Back to top

Environmental Product Compliance

China RoHSSpace of time for the intended use: unlimited = FEUP-e
No dangerous substances above the thresholds
Back to top

Ratings

eCl@ss

eCl@ss 4.0Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 4.1Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 5.0Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 5.1Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 6.0Twenty seven million two hundred sixty thousand seven hundred
eCl@ss 7.0Twenty seven million four hundred forty thousand four hundred two
eCl@ss 8.0Twenty seven million four hundred forty thousand four hundred two
eCl@ss 9.0Twenty seven million four hundred forty thousand four hundred two
Back to top

ETIM

ETIM 3.0EC001121
ETIM 4.0EC002637
ETIM 5.0EC002637
ETIM 6.0EC002637
ETIM 7.0EC002637
Back to top

UNSPSC

UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred one
UNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred thirty two
UNSPSC 11Thirty nine million one hundred twenty one thousand four hundred thirty two
UNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred nine
UNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred nine
UNSPSC 18.0Thirty nine million one hundred twenty one thousand four hundred nine
UNSPSC 19.0Thirty nine million one hundred twenty one thousand four hundred nine
UNSPSC 20.0Thirty nine million one hundred twenty one thousand four hundred nine
UNSPSC 21.0Thirty nine million one hundred twenty one thousand four hundred nine
Back to top

ETIM for 5446370 Connectors (EC002637)
Feature Name Feature Value
Connector model (EF007495) Fixed connector
Contact type (EF001587) Pin
Number of poles (EF001391) 8
Number of plug-in contact rows (EF006935) 1
Modular spacing contacts (EF007326) 5.08 mm
Modular spacing connections (EF006827) 5.08 mm
Rated current In (EF008250) 12 A
Rated voltage (EF000228) 320 V
Rated surge voltage (EF002993) 4 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Material of contact surface (EF004020) Tin
Type of electric connection (EF003961) Other
Diameter connection pin (EF006823) 1.4 mm
Length pin (EF006825) 3.23 mm
Material insulation body (EF007543) Other
Housing colour (EF000136) Other
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
Type of fastening (EF002442) Other
Type of banding (EF007011) Carton (for SMD)

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
