PHOENIX CONTACT BCH-381H-15 BK BCH-381H-15 BK 5452040 PHOENIX CONTACT Housing base,nominal Current: 8 A,rated Voltage (III/2): 160 V,N. º p.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

BCH-381H-15 BK 5452040 PHOENIX CONTACT Housing base,nominal Current: 8 A,rated Voltage (III/2): 160 V,N. º p..

BCH-381H-15 BK

5452040

PHOENIX CONTACT

100 Pcs.

Housing base,nominal Current: 8 A,rated Voltage (III/2): 160 V,N. º poles: 15,Pitch: 3,81 mm,Color: black,contact Surface: Tin,Assembly: wave Soldering Printed circuit board base housing, nominal section: 1.5 mm², color: black, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Male, number of potentials: 15, number of rows: 1, number of poles: 15, number of connections: 15, article family: BCH-H, pitch: 3.81 mm, mounting: Wave soldering, Pin arrangement: Linear pin arrangement, pin length [P]: 3.4 mm, number of solder pins per potential: 1, plug-in system: BASICLINE 1.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Commercial data

Order key5452040
Packaging unit100 pcs
Sell keyAAYBFA -
Minimum Order Quantity100 pcs
Ean4046356855419
Weight per unit (excluding packaging)3,500 g
Tariff rate number85366990
Country of originCN (China)

Dimensions

Length [ l ]9.2 mm
Width58.54 mm
Step3.81 mm
Medium to53.34 mm
Width [ w ]58.54 mm
Height [ h ]10.8 mm
Construction height7.4 mm
Weld pin length3.4 mm
Temple Dimensions0.8 x 0.8 mm
Longitude9.2 mm

General

Article FamilyBCH-H
Insulating material groupI
Dimensioning transient voltage (III/3)2.5 kV
Dimensioning Transient Voltage (III/2)2.5 kV
Dimensioning transient voltage (II/2)2.5 kV
Sizing voltage (III/3)160 V
Dimensioning voltage (III/2)160 V
Sizing voltage (II/2)320 V
Standard-compliant connectionEN-VDE
Nominal Current IN8 A
IsolationPA
Combustibility class according to UL 94V0
Colourblack
Number of poles15

Standards & Specifications

Standard-compliant connectionEN-VDE
CUL
Combustibility class according to UL 94V0

Environmental Product Compliance

China RoHSTime slot for intended use: unlimited = EFUP-e
No hazardous substances above thresholds
