PHOENIX CONTACT BCH-350H-15 BK BCH-350H-15 BK 5452021 PHOENIX CONTACT Printed-circuit board connector View larger
Images are for illustrative purposes only. Please refer to data sheet for details

BCH-350H-15 BK 5452021 PHOENIX CONTACT Printed-circuit board connector

BCH-350H-15 BK

5452021

PHOENIX CONTACT

100 Pcs.

Printed-circuit board connector Printed circuit board base case, nominal section: 1.5 mm², color: black, nominal current: 8 A, nominal voltage (III/2): 160 V, contact surface: Tin, contact type: Male, number of potentials: 15, number of rows: 1, number of poles: 15, number of connections: 15, family of articles: BCH-H, pitch: 3.5 mm, mounting: Wave soldering, Pin arrangement: Linear pin arrangement, pin length [P]: 3.4 mm, number of solder pins per potential: 1, plug-in system: BASICLINE 1.5, Plug-in face orientation: Standard, lock: without, fixing type: without, packaging type: boxed

Connectors > Printed circuit board connector
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Key Commercial Data

Orderkey5452021
Packing unit100 pc
Minimum order quantity100 pc
NoteMade to Order (non-returnable)
GTIN4046356855600
Weight per Piece (excluding packing)3.200 g
Custom tariff number85366930
Country of originCN (China)

Dimensions

Length [ l ]9.2 mm
Width53.9 mm
Pitch3.5 mm
Dimension a49 mm
Width [ w ]53.9 mm
Height [ h ]10.8 mm
Height7.4 mm
Length of the solder pin3.4 mm
Pin dimensions0.8 x 0.8 mm
Length9.2 mm

General

Range of articlesBCH-H
Insulating material groupI
Rated surge voltage (III/3)2.5 kV
Rated surge voltage (III/2)2.5 kV
Rated surge voltage (II/2)2.5 kV
Rated voltage (III/3)160 V
Rated voltage (III/2)160 V
Rated voltage (II/2)320 V
Connection in acc. with standardEN-VDE
Nominal current IN8 A
Insulating materialPA
Flammability rating according to UL 94V0
Colorblack
Number of positions15

Standards and Regulations

Connection in acc. with standardEN-VDE
CUL
Flammability rating according to UL 94V0

Environmental Product Compliance

China RoHSEnvironmentally friendly use period: unlimited = EFUP-e
No hazardous substances above threshold values
