PHOENIX CONTACT BC-350X9-6 BK BC-350X9-6 BK 5452606 PHOENIX CONTACT Terminal p. printed circuit board, rated Current: 13,5 A, rated Voltag.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

BC-350X9-6 BK 5452606 PHOENIX CONTACT Terminal p. printed circuit board, rated Current: 13,5 A, rated Voltag..

BC-350X9-6 BK

5452606

PHOENIX CONTACT

100 Pcs.

Terminal p. printed circuit board, rated Current: 13,5 A, rated Voltage: 200 V, Pitch: 3.5 mm, Number of poles: 6, Type of connection: Connection by screw with capsule-traction, Assembly: Soldering by wave Direction for connection Conductor/pcb: 0 °, Color: black Terminal block for printed circuit board, nominal current: 13.5 A, nominal voltage (III/2): 200 V, nominal cross-section: 1.5 mm², number of potentials: 6, number of rows: 1, number of poles per row: 6, article family: BC-X9, pitch: 3.5 mm, connection type: Screw connection with traction capsule, mounting: Wave soldering, conductor connection direction/printed circuit board: 0°, color: black, Pin arrangement: Linear pin arrangement, Pin length [P]: 3.5 mm, number of solder pins per potential: 1, packaging type: boxed

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Commercial data

Order key5452606
Packaging unit100 pcs
Sell keyAAYAAA -
Minimum Order Quantity100 pcs
Ean4046356849753
Weight per unit (excluding packaging)3,070 g
Tariff rate number85369010
Country of originCN (China)

Dimensions

Length [ l ]7.3 mm
Step3.5 mm
Medium to17.5 mm
Width [ w ]21.5 mm
Construction height8.5 mm
Height [ h ]12 mm
Pin Length [P]3.5 mm
Hole diameter1.1 mm

General

Article FamilyBC-X9
Insulating material groupI
Dimensioning transient voltage (III/3)2.5 kV
Dimensioning Transient Voltage (III/2)2.5 kV
Dimensioning transient voltage (II/2)2.5 kV
Sizing voltage (III/3)160 V
Dimensioning voltage (III/2)200 V
Sizing voltage (II/2)400 V
Standard-compliant connectionEN-VDE
Nominal Current IN13.5 A
Nominal Section1.5 mm²
IsolationPA
Surface Welding Pin
Combustibility class according to UL 94V0
Length to be de-insulated5 mm
Number of poles6
Screw threadM2
Min. tightening torque.0.22 Nm
Max. tightening torque.0.25 Nm

Connection data

Rigid conductor section min.0.14 mm²
Max. rigid conductor section1.5 mm²
Flexible conductor section min.0.14 mm²
Max. flexible conductor section1.5 mm²
Flexible conductor section with toe cap, without min plastic sleeve.0.25 mm²
Flexible conductor section with toe cap, without plastic sleeve max.0.5 mm²
Flexible conductor section with tip, with min plastic sleeve.0.25 mm²
Flexible conductor section with ferrule, with plastic sleeve max.0.5 mm²
Conductor section AWG min.26
Conductor section AWG max.16
2 conductors with the same cross-section, rigid min.0.14 mm²
2 conductors with the same cross-section, rigid max.0.5 mm²
2 conductors with the same cross-section, flexible min.0.14 mm²
2 conductors with the same cross-section, flexible max.0.34 mm²

Standards & Specifications

Standard-compliant connectionEN-VDE
CUL
Combustibility class according to UL 94V0

Environmental Product Compliance

REACh SVHCLead 7439-92-1
China RoHSTime Span for Intended Use (EFUP): 50 years
You can find information about hazardous substances in the manufacturer's declaration under the "Downloads" tab

Classifications


ETIM for 5452606 Connectors (EC002643)
Feature Name Feature Value
Height (EF000040) 12 mm
Number of electrical connections (EF008252) 6
Number of levels (EF002659) 1
Modular spacing connections (EF006827) 3.5 mm
Rated current In (EF008250) 13.5 A
Rated voltage (EF000228) 200 V
Rated surge voltage (EF002993) 2.5 kV
Over voltage category (EF006785) III
Pollution degree (EF006786) 2
Connection type conductor (EF006821) Screw connection
Connectable conductor cross section solid-core (EF007337) 0.14 mm²
Connectable conductor cross section fine-strand with cable end sleeve (EF007339) 0.25 mm²
Connectable conductor cross section fine-strand without cable end sleeve (EF007341) 0.14 mm²
Connectable conductor cross section multi-wired (EF007343) 0.14 mm²
Connection type PCB (EF006822) Soldering connection
Material connection surface (EF006826) Tin
Diameter connection pin (EF006823) 1.1 mm
Length pin (EF006825) 3.5 mm
Material insulation body (EF007543) Other
Housing colour (EF000136) Black
Inflammability class of insulation material according to UL94 (EF002521) V0
Operating temperature (EF002393) -40 °C
Type of PCB fastening (EF008226) Connecting contact
Type of fastening (EF002442) Solder
Type of banding (EF007011) Carton (for SMD)

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
