BC-350X9- 4 BK 5452604 PHOENIX CONTACT Terminal p. printed circuit board, rated Current: 13,5 A, rated Volta..
BC-350X9-4 BK
5452604
PHOENIX CONTACT
100 Pcs.
Terminal p. printed circuit board, rated Current: 13,5 A, rated Voltage: 200 V, Pitch: 3.5 mm, Number of poles: 4, Type of connection: Connection by screw with capsule-traction, Assembly: Soldering by wave Direction for connection Conductor/pcb: 0 °, Color: black
Terminal block for printed circuit board, nominal current: 13.5 A, nominal voltage (III/2): 200 V, nominal cross-section: 1.5 mm², number of potentials: 4, number of rows: 1, number of poles per row: 4, article family: BC-X9, pitch: 3.5 mm, connection type: Screw connection with traction capsule, mounting: Wave soldering, conductor connection direction/printed circuit board: 0°, color: black, Pin arrangement: Linear pin arrangement, Pin length [P]: 3.5 mm, number of solder pins per potential: 1, packaging type: boxed
Connectors > Printed circuit board terminal
PCB Connectors (PCC)
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Commercial data
| The code for the order | Five million four hundred fifty two thousand six hundred four |
|---|---|
| Pieces/pack. | 100 PCS |
| Sales key | AAYAAA - |
| The amount of minimum order | 100 PCS |
| GTIN | Four trillion forty six billion three hundred fifty six million eight hundred forty nine thousand seven hundred seventy seven |
| Weight per piece (package included) | 1,800 g |
| Number customs tariff | Eighty five million three hundred sixty nine thousand ten |
Size
| Length [ l ] | 7.3 mm |
|---|---|
| Step | 3.5 mm |
| Measure | 10.5 mm |
| Width [ w ] | 14.5 mm |
| Mounting height | 8.5 mm |
| Height [ h ] | 12 mm |
| Length of pin [P] | 3.5 mm |
| Hole diameter | 1.1 mm |
General
| Family article | BC-X9 |
|---|---|
| Group insulating material | The |
| Surge voltage strength (III/3) | 2.5 kV |
| Surge voltage strength (III/2) | 2.5 kV |
| Surge voltage strength (II/2) | 2.5 kV |
| Rating voltage (III/3) | 160 V |
| Rating voltage (III/2) | 200 V |
| Rating voltage (II/2) | 400 V |
| Attack in accordance with | EN-VDE |
| Rated current IN | 13.5 A |
| Nominal section | 1.5 mm2 |
| Insulating material | PA |
| Surface of the pin welding | |
| Class behaviour according to UL 94 | V0 |
| Stripping length | 5 mm |
| N. of poles | Four |
| Thread | M2 |
| Torque min. | 0,22 Nm |
| Torque, max. | 0,25 Nm |
Data link
| Conductor cross section, rigid min. | 0.14 mm2 |
|---|---|
| Conductor cross section, rigid max. | 1.5 mm2 |
| Conductor cross section flexible min. | 0.14 mm2 |
| Conductor cross section flexible max. | 1.5 mm2 |
| Conductor cross section flexible with crimp connector without collar plastic min. | 0.25 mm2 |
| Conductor cross section flexible with crimp connector without collar plastic max. | 0.5 mm2 |
| Conductor cross section flexible with aeh with collar plastic min. | 0.25 mm2 |
| Conductor cross section flexible with aeh with collar plastic max. | 0.5 mm2 |
| Cross section conductor AWG min. | Twenty six |
| Cross section conductor AWG max. | Sixteen |
| 2 conductors with the same diameter, rigid min. | 0.14 mm2 |
| 2 conductors with the same diameter, rigid max. | 0.5 mm2 |
| 2 conductors with the same diameter, flexible, min. | 0.14 mm2 |
| 2 conductors with the same diameter, flexible, max. | 0.34 mm2 |
Environmental Product Compliance
| REACh SVHC | Lead 7439-92-1 |
|---|---|
| China RoHS | Period of use conforms to the target without damage to the environment (EFUP): 50 years |
| The information on hazardous substances found in the declaration of the manufacturer under "Downlaods" |
Rankings
eCl@ss 4.0Twenty seven million one hundred forty one thousand one hundred eleveneCl@ss 4.1Twenty seven million one hundred forty one thousand one hundred nineeCl@ss 5.0Twenty seven million one hundred forty one thousand one hundred ninetyeCl@ss 5.1Twenty seven million two hundred sixty one thousand one hundredeCl@ss 6.0Twenty seven million two hundred sixty one thousand one hundredeCl@ss 7.0Twenty seven million four hundred forty thousand four hundred oneeCl@ss 8.0Twenty seven million four hundred forty thousand four hundred oneeCl@ss 9.0Twenty seven million four hundred forty thousand four hundred one
UNSPSC 6.01Thirty million two hundred eleven thousand eight hundred tenUNSPSC 7.0901Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 11Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 12.01Thirty nine million one hundred twenty one thousand four hundred nineUNSPSC 13.2Thirty nine million one hundred twenty one thousand four hundred thirty two
| Feature Name | Feature Value |
|---|---|
| Height (EF000040) | 12 mm |
| Number of electrical connections (EF008252) | 4 |
| Number of levels (EF002659) | 1 |
| Modular spacing connections (EF006827) | 3.5 mm |
| Rated current In (EF008250) | 13.5 A |
| Rated voltage (EF000228) | 200 V |
| Rated surge voltage (EF002993) | 2.5 kV |
| Over voltage category (EF006785) | III |
| Pollution degree (EF006786) | 2 |
| Connection type conductor (EF006821) | Screw connection |
| Connectable conductor cross section solid-core (EF007337) | 0.14 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve (EF007339) | 0.25 mm² |
| Connectable conductor cross section fine-strand without cable end sleeve (EF007341) | 0.14 mm² |
| Connectable conductor cross section multi-wired (EF007343) | 0.14 mm² |
| Connection type PCB (EF006822) | Soldering connection |
| Material connection surface (EF006826) | Tin |
| Diameter connection pin (EF006823) | 1.1 mm |
| Length pin (EF006825) | 3.5 mm |
| Material insulation body (EF007543) | Other |
| Housing colour (EF000136) | Black |
| Inflammability class of insulation material according to UL94 (EF002521) | V0 |
| Operating temperature (EF002393) | -40 °C |
| Type of PCB fastening (EF008226) | Connecting contact |
| Type of fastening (EF002442) | Solder |
| Type of banding (EF007011) | Carton (for SMD) |
