PHOENIX CONTACT BC-350X9-11 BK BC-350X9-11 BK 5452611 PHOENIX CONTACT Terminal p. printed circuit board, rated Current: 13,5 A, rated Volta.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

BC-350X9-11 BK 5452611 PHOENIX CONTACT Terminal p. printed circuit board, rated Current: 13,5 A, rated Volta..

BC-350X9-11 BK

5452611

PHOENIX CONTACT

100 Pcs.

Terminal p. printed circuit board, rated Current: 13,5 A, rated Voltage: 200 V, Pitch: 3.5 mm, Number of poles: 11, Type of connection: Connection by screw with capsule-traction, Assembly: Soldering by wave Direction for connection Conductor/pcb: 0 °, Color: black Terminal block for printed circuit board, nominal current: 13.5 A, nominal voltage (III/2): 200 V, nominal cross-section: 1.5 mm², number of potentials: 11, number of rows: 1, number of poles per row: 11, article family: BC-X9, pitch: 3.5 mm, connection type: Screw connection with traction capsule, mounting: Wave soldering, conductor connection direction/printed circuit board: 0°, color: black, Pin arrangement: Linear pin arrangement, Pin length [P]: 3.5 mm, number of solder pins per potential: 1, packaging type: boxed Printed circuit board terminal, rated current: 13.5 A, rated voltage (III/2): 200 V, rated cross-section: 1.5 mm2, number of potentials: 11, number of rows: 1, number of poles per row: 11, article family: BC-X9, pitch: 3.5 mm, connection type: Screw connection with traction capsule, screw clamping form: L Longitudinal slot, mounting: Wave soldering, conductor/printed circuit board connection direction: 0 °, color: black, Pin arrangement: Linear pin arrangement, Pin length [P]: 3.5 mm, number of solder pins per potential: 1, packaging type: boxed

Connectors > Printed circuit board terminal
PCB Connectors (PCC)

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

Data commercial

Key orderFive million four hundred fifty two thousand six hundred eleven
Packing unit100 pcs
Key sellingAAYAAA -
Minimum order quantity100 pcs
EANFour trillion forty six billion three hundred fifty six million eight hundred forty nine thousand seven hundred eight
Unit weight (excluding packaging)5,400 g
Tariff number tariffEighty five million three hundred sixty nine thousand ten
Country of originCN (China)

Dimensions

Length [ l ]7,3 mm
Step3.5 mm
Average35 mm
Width [ w ]39 mm
Height of construction8.5 mm
Height [ h ]12 mm
Length of pin [P]3.5 mm
Diameter hole1.1 mm

Overview

Family of articlesBC-X9
Group insulating materialI
Transient voltage design (III/3)2.5 kV
Transient voltage design (III/2)2.5 kV
Transient voltage design (II/2)2.5 kV
Tension and sizing (III/3)160 V
Tension and sizing (III/2)200 V
Tension and sizing (II/2)400 V
Connection according to standardEN-VDE
Nominal current IN13.5 To
Nominal cross section1.5 mm2
IsolationPA
Surface pin welding
Class of flammability according to UL 94V0
Length desaislar5 mm
Number of polesEleven
Screw threadM2
Tightening torque min.0.22 Nm
Tightening torque max.0,25 Nm

Data connection

Core cross-section rigid min.0.14 mm2
Section of conductor rigid max.1.5 mm2
Section of flexible conductor, min.0.14 mm2
Section of flexible conductor max.1.5 mm2
Section of flexible conductor with toe cap, without plastic sleeve min.0.25 mm2
Section of flexible conductor with toe cap, without plastic sleeve max.0.5 mm2
Section of flexible conductor with toe, with plastic sleeve min.0.25 mm2
Section of flexible conductor with toe, with plastic sleeve max.0.5 mm2
Section of conductor AWG min.Twenty six
Section of conductor AWG max.Sixteen
2 conductors with same cross section, rigid min.0.14 mm2
2 conductors with same cross section, rigid max.0.5 mm2
2 conductors with same cross section, flexible, min.0.14 mm2
2 conductors with same cross section, flexible max.0,34 mm2

Standards and specifications

Connection according to standardEN-VDE
CUL
Class of flammability according to UL 94V0

Environmental Product Compliance

REACh SVHCLead 7439-92-1
China RoHSSpace of time for the intended use (FEUP): 50 years
You will find information about hazardous substances in the manufacturer's declaration in the "Downloads"tab
