PANASONIC UFT40V UFT40V FT-40V PANASONIC Vacuum resistant optical fiber, barrier, M4, temperature range -30 to 300°C, detecti.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

UFT40V FT-40V PANASONIC Vacuum resistant optical fiber, barrier, M4, temperature range -30 to 300°C, detecti..

UFT40V

UFT40V

PANASONIC

1 unit


Automation > Fiber - PANASONIC
VACUUM-RESISTANT type optical fibers

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Vacuum resistant optical fiber, barrier, M4, temperature range -30 to 300°C, detecti.. produced by Panasonic, identified by part number UFT40V, transmits light signals in extreme thermal environments and pressurized chambers where standard fiber optics would fail. Industrial engineers deploy specialized thru-beam optical fibers for precise object detection inside ovens, furnaces, and vacuum chambers.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Product Number: FT-40V
  • Part Number: FT-40V
  • Product: Thru-beam type Fiber
  • Details: Vacuum-resistant Fiber
  • Product name: One-Touch Connection System Vacuum-resistant Fibers
  • Sensing mode: Thru-beam type
  • Fiber type: Vacuum-resistant
  • Fiber head dia.: M4
  • Fiber head length: 30 mm
  • With sleeve: No
  • Beam direction: Top-view
  • Beam axis dia./ Spot diameter: dia. 1.3 mm

More info

▲
Product NumberFT-40V
Part NumberFT-40V
ProductThru-beam type Fiber
DetailsVacuum-resistant Fiber
Product nameOne-Touch Connection System Vacuum-resistant Fibers

ItemSpecifications
Product NumberFT-40V
Part NumberFT-40V
Sensing modeThru-beam type
Fiber typeVacuum-resistant
Fiber type(レンジ指定)Particular use
Fiber head dia.M4
Fiber head dia.(レンジ指定)02##M4
Fiber head length30 mm
With sleeveNo
Beam directionTop-view
Beam axis dia./ Spot diameterdia. 1.3 mm
Fiber cable length1m
Allowable bending radiusR25mm
Allowable bending radius(レンジ指定)08##R25mm
Free-cutNot available
Semi-customFiber length change
Mounting lensAvailable
Applicable lensFV-LE1, FV-SV1, FV-SV2
Mounting protective tubeNot available
ApplicationVacuum-resistant
Environmental resistance : Ambient temperature MAX300 degrees
Environmental resistance : Ambient temperature MAX(レンジ指定)06##201-300 degrees
Environmental resistance : Ambient temperature MIN-30 degrees
Environmental resistance : Ambient temperature MIN(レンジ指定)04##-30 degrees
Sensing range(範囲)07##701-1000mm
Sensing range(STD)270 mm 10.630 in (FX-500 series)
Sensing range(HYPR)1,000 mm 39.370 in (FX-500 series)
Sensing range(U-LG)590 mm 23.228 in (FX-500 series)
Sensing range(LONG)470 mm 18.504 in (FX-500 series)
Sensing range(FAST)160 mm 6.299 in (FX-500 series)
Sensing range(H-SP)55 mm 2.165 in (FX-500 series)
