Product Overview

Panasonic UEXF1 EXF1 EX-F1 Pipe mountable liquid level sensor, NPN, 12-24 V DC serves as a specialized detector designed to monitor liquid levels externally on piping systems in industrial environments. These sensors are widely deployed in fluid processing, chemical dispensing, and manufacturing equipment to reliably signal the presence or absence of internal media without direct contact. Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Product Number: EX-F1
  • Part Number: EX-F1
  • Product: Pipe-mountable Liquid Level Detection Sensor
  • Details: Amplifier built-in, Pipe-mountable
  • Product name: Pipe-mountable Liquid Level Detection Sensor EX-F1
  • CE marking directive compliance: EMC Directive, RoHS Directive
  • Sensing object: Liquid (Note):Unclear or highly viscous liquid may not be detected stably.
  • Supply voltage: 12 to 24 V DC ± 10 % Ripple P-P 10 % or less
  • Current consumption: 30 mA or less (Note:Unclear or highly viscous liquid may not be detected stably.)
  • Output:Output operation: Switchable either Light-ON (Liquid-absent-ON) or Dark-ON (Liquid-present-ON)
  • Output:Short-circuit protection: Incorporated
  • Response time: 2 ms or less
  • Operation indicator: Red LED (lights up when the output is ON)
  • Ambient humidity: 35 to 85 % RH, Storage: 35 to 85 % RH

More info

▲
Product Number EX-F1
Part Number EX-F1
Product Pipe-mountable Liquid Level Detection Sensor
Details Amplifier built-in, Pipe-mountable
Product name Pipe-mountable Liquid Level Detection Sensor EX-F1

Item Specifications
Product Number EX-F1
Part Number EX-F1
CE marking directive compliance EMC Directive, RoHS Directive
Sensing object Liquid
(Note):Unclear or highly viscous liquid may not be detected stably.
Applicable pipe diameter Outer dia. ø6 to ø13 mm ø0.236 to ø0.512 in transparent resin pipe
[PFA (Fluorine resin) or equivalently transparent pipe, wall thickness 1 mm 0.039 in ]
(Note:Do not use the sensor with pipes other than the above specified.)
Supply voltage 12 to 24 V DC ± 10 % Ripple P-P 10 % or less
Current consumption 30 mA or less
(Note:Unclear or highly viscous liquid may not be detected stably.)
Output NPN open-collector transistor
- Maximum sink current: 100 mA
- Applied voltage: 30 V DC or less (between output and 0 V)
- Residual voltage: 1 V or less (at 100 mA sink current), 0.4 V or less (at 16 mA sink current)
Output:Output operation Switchable either Light-ON (Liquid-absent-ON) or Dark-ON (Liquid-present-ON)
Output:Short-circuit protection Incorporated
Response time 2 ms or less
Operation indicator Red LED (lights up when the output is ON)
Ambient temperature -10 to +55 ℃+14 to +131 ℉(No dew condensation or icing allowed), Storage: -20 to +70 ℃-4 to +158 ℉
(Note:Liquid being detected should also be kept within the rated ambient temperature range.)
Ambient humidity 35 to 85 % RH, Storage: 35 to 85 % RH
Ambient illuminance lncandescent light: 3,000 lx or less at the light-receiving face
Voltage withstandability 1,000 V AC for one min. between all supply terminals connected together and enclosure
Insulation resistance 20 MΩ, or more, with 250 V DC megger between all supply terminals connected together and enclosure
Vibration resistance 10 to 150 Hz frequency, 0.75 mm0.030 indouble amplitude in X, Y and Z directions for two hours each
Shock resistance 100 m/s2acceleration (10 G approx.) in X, Y and Z directions three times each
Emitting element Infrared LED (modulated)
Material Enclosure: Polycarbonate, Tying band: Nylon, Anti-slip tube: Silicone
Cable 0.1 mm2 3-core cabtyre cable, 1 m 3.281 ft long
Cable extension Extension up to total 50 m164.042 ftis possible with 0.3 mm2, or more, cable.
Weight Net weight: 15 g approx., Gross weight: 60 g approx.
Accessory Tying band: 2 pcs., Anti-slip tube: 2 pcs.
