OMRON E5CB-R1PD 24VAC/DC E5CB-R1PD 24VAC/DC E5CB0004M E5CBR1PDACDC24 OMRON Pt100 Relay Output 1 Alarm 48x48 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

E5CB-R1PD 24VAC/DC E5CB0004M E5CBR1PDACDC24 OMRON Pt100 Relay Output 1 Alarm 48x48

E5CB-R1PD 24VAC/DC

E5CB0004M

E5CBR1PDACDC24

OMRON

1 Pcs.

Pt100 Relay Output 1 Alarm 48x48 Temp. controller, LITE, 1/16DIN (48 x 48mm), relay output, ON/OFF or PID Control, Pt100 RTD input, 1 Alarm Rel., 24 VAC/DC

Automation > Temperature monitoring relay
E5CS-V / E5CB

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A Pt100 relay output temperature controller, specifically the Omron E5CB-R1PD 24VAC/DC, provides reliable thermal management for industrial ovens, packaging machinery, and manufacturing lines. By processing sensor feedback, units of this type execute PID or ON/OFF control strategies to stabilize system temperatures.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Size: 1/16 DIN (48 x 48 mm)
  • Functions: ON/OFF control, PID control
  • Number of control loops: 1
  • Temperature input type: Pt100
  • Temperature range: -200-1700 °C
  • Number of event inputs: 0
  • Number of alarm outputs: 1
  • Supply voltage AC: 20.4-26.4 V
  • Supply voltage DC: 20.4-26.4 V
  • Control output: Relay
  • Terminal type: Screw
  • Voltage type (operating voltage): AC/DC
  • Type of electric connection: Screw connection
  • Voltage type (supply voltage): AC/DC
  • Error registration possible: No
  • External reset possible: No

More info

▲

Specifications

Size1/16 DIN (48 x 48 mm)
FunctionsON/OFF control, PID control
Number of control loops1
Temperature input typePt100
Temperature range-200-1700 °C
Number of event inputs0
Number of alarm outputs1
Supply voltage AC20.4-26.4 V
Supply voltage DC20.4-26.4 V
Control outputRelay
Terminal typeScrew

Accessories

E58-CIFQ2E5CB & E5CC and E5EC* accessory, quick link programming cable, allows direct USB connection without requirement for communications card or power supply. Also the diplay will be powered (CX-Thermo v4.4 is needed). *For E5EC front connection.
Y92F-52DIN mounting adapter for E5CC and E5CB
