OMRON D4N-1A2HR D4N-1A2HR D4NR0055R D4N1A2HR OMRON Manual reset 1NC/1NO Roller adj D50mm PG13,5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-1A2HR D4NR0055R D4N1A2HR OMRON Manual reset 1NC/1NO Roller adj D50mm PG13,5

D4N-1A2HR

D4NR0055R

D4N1A2HR

OMRON

1 Pcs.

Manual reset 1NC/1NO Roller adj D50mm PG13,5 Limit switch, Adjustable roller lever, form lock (metal lever, rubber roller), 1NC/1NO (slow-action), 1NC/1NO (slow-action), Pg13.5 (1-conduit), manua

Automation > End switch
Others

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron D4N-1A2HR Manual reset 1NC/1NO Roller adj D50mm PG13,5 functions as a mechanical limit switch utilized in industrial automation environments to monitor position, limit movement, or signal the presence of moving machine parts.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Alignment of the control element (EF008793): Roller cam straight
  • Type of control element (EF006976): Adjustable roller lever
  • Type of electric connection (EF003961): Cable entry PG
  • Switching function (EF000189): Slow-action switch
  • Housing material (EF001596): Plastic
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 1
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A

More info

▲
  • Direct opening mechanism
  • Various actuators
  • Pull-reset switches
  • Gold-plated contacts for handling micro loads
  • Metric conduit types available
