OMRON D4BS-15FS D4BS-15FS D4BS0001G D4BS15FS OMRON Metal 1NC/1NO PG13,5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4BS-15FS D4BS0001G D4BS15FS OMRON Metal 1NC/1NO PG13,5

D4BS-15FS

D4BS0001G

D4BS15FS

OMRON

10 Pcs.

Metal 1NC/1NO PG13,5 Safety-door switch, PG13.5 (1 conduit), 1NC/1NO (slow-action)

Automation > Position switch with separate actuator
Others

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Heavy-duty safety position switches provide reliable electrical contact closure when monitoring mechanical guards, covers, and movable barriers in manufacturing environments. Encased in a durable metal housing, the Omron D4BS-15FS ensures dependable performance for critical interlock applications.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Type of switching contact (EF003591): Slow-action switch
  • Degree of protection (IP) (EF005474): IP67
  • Type of electric connection (EF003961): Cable entry PG
  • Housing material (EF001596): Metal
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 1
  • Rated operation current Ie at AC-15, 230 V (EF001385): 2 A
  • Number of safety auxiliary contacts (EF006940): 0
  • Number of contacts as normally closed contact (EF008255): 1
  • Width sensor (EF007094): 40 mm
  • Height of sensor (EF007283): 43 mm
  • Length of sensor (EF007334): 111.5 mm

More info

▲
Door switch typeKey-operatedGuard-lockMaterial housingMetalMaterial headMetalAmbient temperature (operating)-40-80 °CDirection of operationAdjustableDoor contacts NC1Door contacts NO1LED indicatorConnection methodTerminal blockCable length0 mDegree of protection (IP)IP67Conduit sizePG13.5Number of conduits1Switch actionSlow actionShapeCuboidOverall length of sensor111.5 mmHeight of sensor43 mmWidth of sensor40 mm
