View larger
Images are for illustrative purposes only. Please refer to data sheet for details
D4NS-9BF D4NS0050F D4NS9BF OMRON Plastic 2NC M12
D4NS-9BF
D4NS0050F
D4NS9BF
OMRON
1 Pcs.
Plastic 2NC M12
Safety interlock switch, 2 NC, 10 A, M12 connector
Automation > Position switch with separate actuator
D4DL/DS/DH/DR/GL/NL/NH/NS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲
Door switch typeKey-operatedGuard-lockMaterial housingResinMaterial headResinAmbient temperature (operating)-30-70 °CDirection of operationAdjustableDoor contacts NC2Door contacts NO0Switch actionSlow actionMake before breakLED indicatorConnection methodConnector M12Cable length0 mDegree of protection (IP)IP67Conduit sizeNot ApplicableNumber of conduits0ShapeCuboidOverall length of sensor110 mmHeight of sensor30 mmWidth of sensor31 mm
| Feature Name | Feature Value |
|---|---|
| Explosion safety category for dust (EF003998) | None |
| Construction type housing (EF004008) | Cuboid |
| Type of switching contact (EF003591) | Slow-action switch |
| Degree of protection (NEMA) (EF011959) | Other |
| Coating housing (EF001601) | Other |
| Degree of protection (IP) (EF005474) | IP67 |
| Type of interface for safety communication (EF003956) | None |
| Type of electric connection (EF003961) | Connector M12 |
| Type of interface (EF006977) | None |
| Housing material (EF001596) | Other |
| Explosion safety category for gas (EF003997) | None |
| With status indication (EF001602) | No |
| Suitable for safety functions (EF001597) | Yes |
| Forced opening (EF006694) | No |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 0 |
| Rated operation current Ie at AC-15, 230 V (EF001385) | 3 A |
| Number of safety auxiliary contacts (EF006940) | 0 |
| Rated operation current Ie at DC-13, 230 V (EF001386) | 0.27 A |
| Number of contacts as normally closed contact (EF008255) | 2 |
| Width sensor (EF007094) | 31 mm |
| Height of sensor (EF007283) | 30 mm |
| Length of sensor (EF007334) | 110 mm |
| Ambient temperature during operating (EF007515) | -30 °C |
