OMRON D4NS-9AF D4NS-9AF D4NS0049B D4NS9AF OMRON Plastic 1NC/1NO M12 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4NS-9AF D4NS0049B D4NS9AF OMRON Plastic 1NC/1NO M12

D4NS-9AF

D4NS0049B

D4NS9AF

OMRON

1 Pcs.

Plastic 1NC/1NO M12 Safety interlock switch, 1 NC/1 NO, 10 A, M12 connector

Automation > Position switch with separate actuator
D4DL/DS/DH/DR/GL/NL/NH/NS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron D4NS-9AF plastic door switch is designed for monitoring safety gates and protective enclosures in automated manufacturing environments. This type of interlock switch ensures industrial machinery remains de-energized whenever safety barriers are displaced.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Door switch type: Key-operated
  • Material body: Resin
  • Material head: Resin
  • Ambient temperature (operating): -30-70 °C
  • Direction of operation: Adjustable
  • Door contacts NC: 1
  • Door contacts NO: 1
  • Connection method: Connector M12
  • Cable length: 0 m
  • Degree of protection (IP): IP67
  • Conduit size: N/A
  • Number of conduits: 0
  • Switch action: Slow action
  • Shape: Cuboid
  • Overall length: 110 mm
  • Height of sensor: 30 mm

More info

▲

Specifications

Door switch typeKey-operated
Guard-lock
Material bodyResin
Material headResin
Ambient temperature (operating)-30-70 °C
Direction of operationAdjustable
Door contacts NC1
Door contacts NO1
With LED indicator
Connection methodConnector M12
Cable length0 m
Degree of protection (IP)IP67
Conduit sizeN/A
Number of conduits0
Switch actionSlow action
ShapeCuboid
Overall length110 mm
Height of sensor30 mm
Width sensor31 mm

Accessories

D4DS-K1Guard lock safety-door switch accessory, D4NL/DS, operation key: horizontal mounting
D4DS-K2Guard lock safety-door switch accessory, D4NL/DS, operation key: vertical mounting
D4DS-K3Guard lock safety-door switch accessory, D4NL/DS, operation key: adjustable mounting (horizontal)
D4DS-K5Guard lock safety-door switch accessory, D4NL/DS, operation key: adjustable mounting (horizontal/vertical)
