OMRON S8VS-18024B S8VS-18024B S8VS0127F S8VS18024B,1 OMRON 180W / 24V / 7,5 A DIN Rail Display-Time func. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

S8VS-18024B S8VS0127F S8VS18024B,1 OMRON 180W / 24V / 7,5 A DIN Rail Display-Time func.

S8VS-18024B

S8VS0127F

S8VS18024B.1

OMRON

1 Pcs.

180W / 24V / 7,5 A DIN Rail Display-Time func. 180W/24V/7.5A DIN Rail Display Time Function Power supply, 180W, 100-240 VAC input, 24 VDC 7.5A output, DIN rail mounting, digital display with running voltage and current, peak current, and tota

Automation > DC-power supply
S8VS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Features

Power Supply with a display

The S8VS-A/B series are AC to DC Power supplies with a display of output voltage, output current, and peak hold current. The A type S8VS has a function to show the maintenance forecast time in operational years. This will contribute to the equipment maintence and allow for replacement before the end of product life. The B type has a function of total run time monitor to allow the user to properly schedule equipment maintenance.

  • Operating temperature range (-10 to +60ºC)
  • The 3 digit, 7 segment display
  • The alarm output(Transistor:PNP, NPN)
  • The screwless terminal type is available
  • cULus, EN, RoHS compliant
  • UL Class 2 output( 60W and 90W)

ETIM for 281066 Low-voltage industrial controls and switchgear (EC002540)
Feature Name Feature Value
Degree of protection (NEMA) (EF011959) Other
Degree of protection (IP) (EF005474) Other
Performance level according to EN ISO 13849-1 (EF007399) None
Type of electric connection (EF003961) Screw connection
SIL according to IEC 61508 (EF009889) None
Voltage type (supply voltage) (EF002991) AC
Wall mounting possible (EF003973) Yes
Stabilized (EF005302) Yes
Output voltage stabilized (EF003092) Yes
Secondary voltage adjustable (EF007002) Yes
Direct mounting possible (EF005689) No
Suitable for safety functions (EF001597) Yes
Short-circuit-proof (EF007332) No
Modular version (EF001126) Yes
Suitable for rail mounting (EF003972) Yes
Power consumption (EF000346) 220 VA
Max. output current 1 (EF008284) 7.5 A
Built-in height (EF000332) 125.3 mm
Built-in width (EF000846) 75.000 mm
Width in number of modular spacings (EF002950) 4.3
Nominal value output voltage 1 (EF009393) 24 V
Width (EF000008) 75 mm
Height (EF000040) 115 mm
Power output (EF003034) 180 W
Nominal value output current 1 (EF009396) 7.5 A
Depth (EF000049) 125.3 mm
Rated supply voltage AC 50 Hz (EF007076) 100 V
Rated supply voltage AC 60 Hz (EF007077) 100 V
1st secondary output voltage (EF006792) 21.6 V
