OMRON E2FM-X1R5C1-M1 E2FM-X1R5C1-M1 E2FM0036D E2FMX1R5C1M1 OMRON Inductive extra-strong Stainless steel 3h Enr 1.5 mm M8 NPN NA M.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

E2FM-X1R5C1-M1 E2FM0036D E2FMX1R5C1M1 OMRON Inductive extra-strong Stainless steel 3h Enr 1.5 mm M8 NPN NA M..

E2FM-X1R5C1-M1

E2FM0036D

E2FMX1R5C1M1

OMRON

1 Pcs.

Inductive extra-strong Stainless steel 3h Enr 1.5 mm M8 NPN NA M12 Proximity sensor, inductive, stainless steel face & body, long body, M8, shielded, 1.5mm, DC, 3-wire, NPN-NO, M12 plug-in

Automation > Inductive proximity switch
Others

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron E2FM-X1R5C1-M1 proximity sensor is a heavy-duty inductive device featuring an all-stainless steel body and face, built to withstand aggressive cleaning agents and mechanical stress. It ensures reliable object detection in food processing and harsh industrial environments.

Exact pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Manufacturer: Omron
  • Manufacturer part number: E2FM-X1R5C1-M1
  • Catalogue code: E2FM0036D
  • Catalogue title: E2FM-X1R5C1-M1 E2FM0036D E2FMX1R5C1M1 OMRON Inductive extra-strong Stainless steel 3h Enr 1.5 mm M8 NPN NA M..
  • Product description: SizeM8Mounting typeFlushSensing distance1.5 mmOutput typeNPNOperation modeNOConnection methodConnector M12Material housingStainless steelCable specifications-Overall length of sensor53 mmThread length25 mmFeaturesMetal s
  • Manufacturer summary: Inductive extra-strong Stainless steel 3h Enr 1.5 mm M8 NPN NA M12 Proximity sensor, inductive, stainless steel face & body, long body, M8, shielded, 1.5mm, DC, 3-wire, NPN-NO, M12 plug-in

More info

▲
SizeM8Mounting typeFlushSensing distance1.5 mmOutput typeNPNOperation modeNOConnection methodConnector M12Material housingStainless steelCable specifications-Overall length of sensor53 mmThread length25 mmFeaturesMetal sensing faceDegree of protection (IP)IP67

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
