View larger
Images are for illustrative purposes only. Please refer to data sheet for details
LY2-0 220/240VAC LY205009F LY20220240AC OMRON DPDT 10A terminals for C. I.
LY2-0 220/240VAC
LY205009F
LY20220240AC
OMRON
50 Pcs.
DPDT 10A terminals for C. I.
Relay, PCB pins, 8-pin, DPDT, 10 A, 220/240 VAC
Automation > Switching relay
LY
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Specifications
| Mounting method | PCB |
| Usage | General purpose |
| Poles | 2 |
| Rated carry current | 10 A |
| Coil voltage | 230 V |
| Operation voltage | AC |
| Contact material | AgSnIn |
| Contact description | DPDT |
| Features | Transparent case |
| Terminal type | PCB |
| Feature Name | Feature Value |
|---|---|
| Type of switch contact (EF003358) | Single contact |
| Drive, polarization (EF003355) | Polarity free |
| Voltage type for actuating (EF008242) | AC |
| Type of electric connection (EF003961) | PCB connection |
| Drive, switching attitude (EF003356) | Mono stable |
| With detachable clamps (EF003340) | No |
| Complete with socket (EF003359) | No |
| With LED indication (EF005950) | No |
| With forced-guided contacts (EF003357) | No |
| Number of contacts as change-over contact (EF008257) | 2 |
| Number of contacts as normally open contact (EF008256) | 0 |
| Width (EF000008) | 21.5 mm |
| Number of contacts as normally closed contact (EF008255) | 0 |
| Height (EF000040) | 28.0 mm |
| Depth (EF000049) | 36.0 mm |
| Nominal current (EF000001) | 10 A |
| Rated control supply voltage AC 60 Hz (EF003979) | 220 V |
| Rated control supply voltage AC 50 Hz (EF003978) | 220 V |
