OMRON LY1F 220/240VAC LY1F 220/240VAC LY1 5024F LY1F220240AC OMRON SPDT 15A enchuf/welding View larger
Images are for illustrative purposes only. Please refer to data sheet for details

LY1F 220/240VAC LY1 5024F LY1F220240AC OMRON SPDT 15A enchuf/welding

LY1F 220/240VAC

LY1 5024F

LY1F220240AC

OMRON

50 Pcs.

SPDT 15A enchuf/welding SPDT 15A Plug/Solder Relay, flange mount, plug-in, SPDT, 15 A, 220/240 VAC

Automation > Switching relay
LY

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Power relays are deployed in industrial installations to handle heavy electrical loads and isolate delicate control circuitry from high-voltage distribution paths. This Omron LY1F 220/240VAC model provides robust single-pole changeover switching capabilities tailored for standard socket or panel installations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Type of switch contact (EF003358): Single contact
  • Drive, polarization (EF003355): Polarity free
  • Voltage type for actuating (EF008242): AC
  • Drive, switching attitude (EF003356): Mono stable
  • With detachable clamps (EF003340): No
  • Complete with socket (EF003359): No
  • With LED indication (EF005950): No
  • With forced-guided contacts (EF003357): No
  • Number of contacts as change-over contact (EF008257): 1
  • Number of contacts as normally open contact (EF008256): 0
  • Width (EF000008): 22.5 mm
  • Number of contacts as normally closed contact (EF008255): 0
  • Height (EF000040): 44.0 mm
  • Depth (EF000049): 35.5 mm
  • Nominal current (EF000001): 15 A
  • Rated control supply voltage AC 60 Hz (EF003979): 176 V
