View larger
K8AK-VS3 24VAC/DC K8AK0016M K8AKVS324VACDC OMRON Single-phase Voltage Max or Min 200-600VAC/DC 24VAC/DC 1SPDT
K8AK-VS3 24VAC/DC
K8AK0016M
K8AKVS324VACDC
OMRON
1 Pcs.
Automation > Voltage monitoring relay
K8AK
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Omron part number K8AK-VS3 24VAC/DC is a single-phase voltage monitoring relay built to detect maximum and minimum thresholds across AC and DC circuits. DIN-rail mounted devices of this type are widely utilized in control panels to protect sensitive automation hardware from voltage sags and surges. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Functions: Voltage
- Installation type: DIN rail
- Terminal type: Screw
- Size: 22.5 mm
- Supply voltage AC: 20.4-26.4 V
- Supply voltage DC: 20.4-26.4 V
- Output type: Relay
- Contact description: SPDT
- Body color: Black
- Type of electric connection (EF003961): Screw connection
- Voltage type (supply voltage) (EF002991): AC/DC
- Type of voltage measuring range (EF003399): AC/DC
- Contains function DC-over voltage (EF003397): Yes
- External power supply required (EF003292): Yes
- Contains function DC-voltage hysteresis (EF003398): Yes
- With detachable clamps (EF003340): No
More info
▲Specifications
| Functions | Voltage |
| Installation type | DIN rail |
| Terminal type | Screw |
| Size | 22.5 mm |
| Supply voltage AC | 20.4-26.4 V |
| Supply voltage DC | 20.4-26.4 V |
| Output type | Relay |
| Contact description | SPDT |
| Body color | Black |
