OMRON K8AK-PW1 K8AK-PW1 K8AK0026G K8AKPW1 OMRON Three-phase Voltage Max and Min 1 SPDT 200-240VAC 2 SPDT View larger
Images are for illustrative purposes only. Please refer to data sheet for details

K8AK-PW1 K8AK0026G K8AKPW1 OMRON Three-phase Voltage Max and Min 1 SPDT 200-240VAC 2 SPDT

K8AK-PW1

K8AK0026G

K8AKPW1

OMRON

1 Pcs.

Three-phase Voltage Max and Min 1 SPDT 200-240VAC 2 SPDT Monitoring relay 22.5 mm wide, 3-phase voltage monitoring, over and under voltages, 3-wire mode: 200, 220, 230 and 240 VAC, 4-wire mode: 115, 127, 133

Automation > Phase monitoring relay
K8AK

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Supervise critical power supplies with the Omron K8AK-PW1, a reliable three-phase voltage monitoring device built for harsh industrial environments. Monitoring relays are essential components in electrical panels, protecting valuable hardware against phase anomalies and voltage drops.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Type of electric connection (EF003961): Screw connection
  • Voltage type (supply voltage) (EF002991): AC
  • With detachable clamps (EF003340): No
  • Phase imbalance monitoring (EF003416): No
  • Phase sequence monitoring (EF003412): No
  • Function under voltage detection (EF003414): Yes
  • Function over voltage detection (EF003415): Yes
  • Phase failure detection (EF003413): No
  • Number of contacts as change-over contact (EF008257): 2
  • Number of contacts as normally open contact (EF008256): 0
  • Min. adjustable delay-on energization time (EF008190): 0.1 s
  • Max. permitted delay-on energization time (EF008189): 30 s
  • Min. adjustable off-delay time (EF008192): 0 s
  • Width (EF000008): 22.5 mm
  • Number of contacts as normally closed contact (EF008255): 0
  • Height (EF000040): 90 mm

More info

▲
  • Overvoltages or undervoltages: Operation time setting from 0.1 to 30 s
  • Relay warning status can easily be monitored using the LED indicator
  • Separate outputs possible for overvoltages and undervoltages
  • Reset method: Automatic
  • Power ON lock: 1 s or 5 s
