OMRON HL-5300G HL-5300G HL5 5428D HL5300GOMR OMRON Compact Rod elastic IP65 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

HL-5300G HL5 5428D HL5300GOMR OMRON Compact Rod elastic IP65

HL-5300G

HL5 5428D

HL5300GOMR

OMRON

1 Pcs.

Compact Rod elastic IP65 Limit switch, Coil spring, With ground terminal

Automation > End switch
HL

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron HL-5300G is a compact metal spring-rod limit switch engineered to detect objects approaching from arbitrary or unpredictable directions. Spring-rod switches are widely specified in winding machinery, automated material feeders, and sorting chutes where flexible mechanical activation is essential. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP65
  • Type of control element (EF006976): Spring-rod
  • Type of electric connection (EF003961): Plug-in connection others
  • Housing material (EF001596): Metal
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): No
  • Forced opening (EF006694): No
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 1
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 4 A
  • Number of safety auxiliary contacts (EF006940): 0
  • Rated operation current Ie at DC-13, 230 V (EF001386): 4 A
  • Number of contacts as normally closed contact (EF008255): 1
