OMRON HL-5050G HL-5050G HL5 5422E HL5050GOMR OMRON Compact Lever rod adjustable IP65 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

HL-5050G HL5 5422E HL5050GOMR OMRON Compact Lever rod adjustable IP65

HL-5050G

HL5 5422E

HL5050GOMR

OMRON

1 Pcs.

Compact Lever rod adjustable IP65 Limit switch, Adjustable rod lever, With ground terminal

Automation > End switch
HL

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The HL-5050G OMRON Compact Lever rod adjustable IP65 functions as a compact limit switch used in tight industrial spaces to detect physical positioning and movement limits of automated machinery. These general-purpose sensors interrupt or establish control circuits when contacted by moving components, ensuring precise operational limits.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP65
  • Type of control element (EF006976): Actuating rod
  • Type of electric connection (EF003961): Plug-in connection others
  • Housing material (EF001596): Metal
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): No
  • Forced opening (EF006694): No
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 1
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 4 A
  • Number of safety auxiliary contacts (EF006940): 0
  • Rated operation current Ie at DC-13, 230 V (EF001386): 4 A
  • Number of contacts as normally closed contact (EF008255): 1

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
