G7J-3A1B-P 100/120VAC G7J 1002D G7J3A1BPAC100120 OMRON 3NA + 1NC 25A
G7J-3A1B-P 100/120VAC
G7J 1002D
G7J3A1BPAC100120
OMRON
20 Pcs.
Automation > Switching relay
G7 Power
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Designed for heavy-duty switching applications, the G7J-3A1B-P 100/120VAC G7J 1002D G7J3A1BPAC100120 OMRON 3NA + 1NC 25A power relay controls high-capacity industrial loads, motors, and heating elements within automation systems. Power relays provide dependable multi-pole switching to handle substantial electrical currents safely. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- 4PST-NO: yes
- no: yes
- yes: no
- 3PST-NO/SPST-NC: yes
- no: yes
- DPST-NO/SPST-NC: yes
- DPST-NO/DPST-NC: yes
- G7J Screw terminal type: R99-04 for G5F
- DC: 6, 12, 24, 48, 100
- Rated load: NO: 25 A at 220 VAC (24 A at 230 VAC) NC: 8 A at 220 VAC (7.5 A at 230 VAC)
- Rated carry current: NO: 25 A (1 A), NC: 8 A (1 A)
- Max. switching voltage: 250 VAC
- Max. switching current: NO: 25 A (1 A), NC: 8 A (1 A)
- Mechanical life: 1,000,000 operations min.
- Electrical life: 100,000 operations min.
- Contact material: Ag alloy
More info
▲A high-capacity multi-pole relay used like a contactor
With a rated load current of 25A due to the miniature hinge for maximum switching power, the G7J can switch both motor loads as well as resistive and inductive loads. G7J has no contact chattering for momentary voltage drops up to 50% of its rated voltage.
- 4PST-NO, 3PST-NO / SPST-NC or DPST-NO / DPST-NC contact types
- Quick-connect, PCB or screw terminals
- 25A rated load
- Compatible with momentary voltage drops
- Can be used like a contactor
