G7J-2A2B-B 200/240VAC G7J 1021M G7J2A2BB200240AC OMRON 2NA + 2NC 25A TerminalesTornillo
G7J-2A2B-B 200/240VAC
G7J 1021M
G7J2A2BB200240AC
OMRON
20 Pcs.
Automation > Switching relay
G7 Power
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Built for demanding power distribution duties, the Omron G7J-2A2B-B 200/240VAC acts as a high-capacity power relay capable of managing heavy electrical loads inside motor control centers and automated production lines. Such switching hardware safeguards primary circuits by providing reliable galvanic isolation and high-current operational capability.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- 4PST-NO: yes
- no: yes
- yes: no
- 3PST-NO/SPST-NC: yes
- no: yes
- DPST-NO/SPST-NC: yes
- DPST-NO/DPST-NC: yes
- G7J Screw terminal type: R99-04 for G5F
- DC: 6, 12, 24, 48, 100
- Rated load: NO: 25 A at 220 VAC (24 A at 230 VAC) NC: 8 A at 220 VAC (7.5 A at 230 VAC)
- Rated carry current: NO: 25 A (1 A), NC: 8 A (1 A)
- Max. switching voltage: 250 VAC
- Max. switching current: NO: 25 A (1 A), NC: 8 A (1 A)
- Mechanical life: 1,000,000 operations min.
- Electrical life: 100,000 operations min.
- Contact material: Ag alloy
More info
▲A high-capacity multi-pole relay used like a contactor
With a rated load current of 25A due to the miniature hinge for maximum switching power, the G7J can switch both motor loads as well as resistive and inductive loads. G7J has no contact chattering for momentary voltage drops up to 50% of its rated voltage.
- 4PST-NO, 3PST-NO / SPST-NC or DPST-NO / DPST-NC contact types
- Quick-connect, PCB or screw terminals
- 25A rated load
- Compatible with momentary voltage drops
- Can be used like a contactor
