E69-DF10 E69 1104C E69DF10,1 OMRON Cable alagador 10m Absolute
E69-DF10
E69 1104C
E69DF10.1
OMRON
1 Pcs.
Automation > Sensor-actuator patch cord
Accessories
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The Omron E69-DF10 extension cable extends the reach of rotary encoders and measurement sensors within industrial motion control setups. Signal extension cables maintain precise data transmission across extended distances between encoders and controller units.
Pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- 5 to 12 VDC: Open-collector output
- 12 to 24 VDC: E6CP-AG5C 256P/R 2M
- Supported: E6CP-AG5C-C 256P/R 2M
- Couplings: Provided with the E6CP-AG3C and E6CP-AG5C.
- Different end diameter: E69-C68B
- Different end diameter: E69-C610B
- Metal construction: E69-C06M
- Servo Mounting Bracket: Provided with the product. (Three brackets in a set.)
- Extension Cable: 5 m
- 10 m: E69-DF10
- 20 m: E69-DF20
- Power supply voltage: 5 VDC −5% to 12 VDC +10%, ripple (p-p): 5% max.
- Current consumption 1: 90 mA max.
- Resolution (rotations): 256 (8-bit)
- Output code: Gray code
- Output configuration: Open-collector output
More info
▲E6CP-A
Low-cost Encoder with Diameter of 50 mm
- Absolute model
- External diameter of 50 mm
- Resolution: 256 (8-bit)
- Lightweight construction using plastic body
Encoders
Note:When connecting to the H8PS, use the E6CP-AG5C-C, which is connected using a connector. It cannot be used on other models.
Accessories (Order Separately)
Specifications
Current consumption1 | ||||
Maximum response frequency2 | ||||
Output code incremented by CW (as viewed from the end of the shaft) | ||||
1 μs max. (Control output voltage: 16 V, Load resistance: 1 kΩ, Output cable: 2 m max.) | ||||
Operating: −10 to 55°C (with no icing), Storage: −25 to 85°C (with no icing) | ||||
200 MΩ min. (at 500 VDC) between current-carrying parts and case | ||||
500 VAC, 50/60 Hz for 1 min between current-carrying parts and case | ||||
Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions | ||||
Destruction: 1,000 m/s2 3 times each in X, Y, and Z directions | ||||
Degree of protection3 | ||||
Case: ABS, Main unit: PPS, Shaft: SUS416, Mounting Bracket: Galvanized iron | ||||
| Coupling (excluding Connector Models), Servo Mounting Bracket, Hexagonal wrench (excluding Connector Models), Instruction manual | ||||
1.An inrush current of approximately 8 A will flow for approximately 0.3 ms when the power is turned ON.
