OMRON E5C2-R20K 100-240VAC 0-600 E5C2-R20K 100-240VAC 0-600 E5C26005A E5C2R20KAC1002400600 OMRON ON/OFF Thermocouple K 0-600ºC, 48x48 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

E5C2-R20K 100-240VAC 0-600 E5C26005A E5C2R20KAC1002400600 OMRON ON/OFF Thermocouple K 0-600ºC, 48x48

E5C2-R20K 100-240VAC 0-600

E5C26005A

E5C2R20KAC1002400600

OMRON

1 Pcs.

ON/OFF Thermocouple K 0-600ºC, 48x48 Temp. controller, LITE, 1/16 DIN, 48x48mm,Dial knob,On-Off Control,K-Thermocouple,0-600deg.,100-240V AC

Automation > Temperature monitoring relay
E5C2

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron E5C2-R20K 100-240VAC 0-600 is a straightforward ON/OFF temperature controller designed to operate with thermocouple K sensors up to 600 °C in a 48x48 mm housing. This device is widely relied upon for basic thermal regulation in furnaces, kilns, and packaging equipment.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type (operating voltage) (EF005294): AC
  • Type of electric connection (EF003961): Plug-in connection
  • Voltage type (supply voltage) (EF002991): AC
  • Error registration possible (EF003423): No
  • External reset possible (EF003426): No
  • With detachable clamps (EF003340): No
  • Number of contacts as change-over contact (EF008257): 1
  • Number of contacts as normally open contact (EF008256): 0
  • Width (EF000008): 48 mm
  • Number of contacts as normally closed contact (EF008255): 0
  • Number of measuring circuits (EF003425): 1
  • Height (EF000040): 48 mm
  • Depth (EF000049): 101.7 mm
  • Supply voltage AC 50 Hz (EF007532): 100 V
  • Supply voltage AC 60 Hz (EF007533): 100 V

More info

▲
Size1/16 DIN (48 x 48 mm)FunctionsON/OFF controlNumber of control loops1Temperature input typeKTemperature range0-600 °CNumber of alarm outputs0Supply voltage AC100-240 VControl outputRelayTerminal typePlug-in
