> OMRON > Photoelectric sensors > E3FA / E3RA > E3RA2003D
OMRON E3RA-DN12 2M E3RA-DN12 2M E3RA2003D E3RADN122MOMI OMRON Plastic Axial Reflex 300mm NPN Cable 2m View larger
Images are for illustrative purposes only. Please refer to data sheet for details

E3RA-DN12 2M E3RA2003D E3RADN122MOMI OMRON Plastic Axial Reflex 300mm NPN Cable 2m

E3RA-DN12 2M

E3RA2003D

E3RADN122MOMI

OMRON

1 Pcs.

Plastic Axial Reflex 300mm NPN Cable 2m Photoelectric sensor, M18 threaded barrel, radial type, plastic, red LED, diffuse, 300 mm, NPN, Light-ON/Dark-ON, 2 m cable

Automation > Diffuse reflective photoelectric sensor
E3FA / E3RA

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Utilizing optical beams for non-contact detection, the Omron E3RA-DN12 2M photoelectric sensor provides reliable object tracking and presence monitoring in manufacturing environments. These cylindrical automation components are standard across conveyor systems and assembly equipment to trigger downstream logic functions. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type (EF000187): DC
  • Construction type housing (EF004008): Cylinder, screw-thread
  • Degree of protection (IP) (EF005474): IP67
  • Setting procedure (EF003994): Manual adjustment
  • Material of optical surface (EF004134): Plastic
  • Sensing mode (EF007503): Light-/dark switching
  • Type of switch function (EF003963): Programmable/configurable
  • Type of electric connection (EF003961): Cable
  • Housing material (EF001596): Plastic
  • Type of light (EF004029): Polarity free red light
  • Material of cable sheath (EF004136): Polyvinyl chloride (PVC)
  • Type of switching output (EF003962): NPN
  • Operation agent-safety class (EF003982): Safety class 3
  • With communication interface RS-485 (EF007314): No
  • Analogue output -10 V ... +10 V (EF006809): No
  • With communication interface SSD (EF007315): No

More info

▲
ShapeCylindrical radialSensing methodDiffuse reflectiveSensing distance300 mmSetting methodManual adjustmentConnection methodCableCable length2 mOutput typeNPNOperation modeDark-ON, Light-ONResponse time0.5 msMaterial housingABSThread sizeM18Product Length (unpacked)54 mmType of lightPolarity free red lightPower supply voltage10-30 VDegree of protection (IP)IP67/IP69K

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
