E3F1-DP22 E3F12015G E3F1DP22OMI OMRON Plastic Reflex 300mm PNP M12 Connector Lite
E3F1-DP22
E3F12015G
E3F1DP22OMI
OMRON
1 Pcs.
Automation > Diffuse reflective photoelectric sensor
E3F1
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Omron E3F1-DP22 is a cylindrical reflex photoelectric sensor designed for compact integration into industrial machinery and control panels. Diffuse reflective sensors are commonly deployed to detect parts on conveyor belts without requiring separate reflector units. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Shape: Cylindrical axial
- Sensing method: Diffuse reflective
- Sensing distance: 300 mm
- Setting method: Manual adjustment
- Connection method: Connector M12
- Output type: PNP
- Operation mode: Dark-ON, Light-ON
- Response time: 0.5 ms
- Material housing: ABS
- Thread size: M18
- Length: 34.5 mm
- Type of light: Polarity free red light
- Power supply voltage: 10-30 V
- Voltage type (EF000187): DC
- Construction type housing (EF004008): Cylinder, screw-thread
- Degree of protection (IP) (EF005474): IP66
More info
▲Specifications
| Shape | Cylindrical axial |
| Sensing method | Diffuse reflective |
| Sensing distance | 300 mm |
| Setting method | Manual adjustment |
| Connection method | Connector M12 |
| Output type | PNP |
| Operation mode | Dark-ON, Light-ON |
| Response time | 0.5 ms |
| Material housing | ABS |
| Thread size | M18 |
| Length | 34.5 mm |
| Type of light | Polarity free red light |
| Power supply voltage | 10-30 V |
Accessories
| E39-L182 | E3FA/R flush mounting bracket | |
| E39-L183 | M18 L-type mounting bracket, stainless steel (SUS304) |
