View larger
Images are for illustrative purposes only. Please refer to data sheet for details
D4NL-4GDA-B4 D4NL0144B D4NL4GDAB4 OMRON Lock makan desert/Opening solen.110Vcc 3nc contact forms+1NC/1NO LED..
D4NL-4GDA-B4
D4NL0144B
D4NL4GDAB4
OMRON
1 Pcs.
Lock makan desert/Opening solen.110Vcc 3nc contact forms+1NC/1NO LED M20
Locking /Opening solen.110Vcc 3NC+1NC/1NA LED M20
Guard lock safety-door switch, M20 entry, 3NC + 1NC/1NO, metal head, mechanical lock, 24 VDC,
Automation > Position switch with guard locking
D4DL/DS/DH/DR/GL/NL/NH/NS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲- Safety door switch with electromagnetic lock or unlock mechanism
- Models with four or five built-in contacts
- Strong key holding force: 1300N
- For standard loads and micro loads
- Keys are compatible with D4GL and D4NS
| Feature Name | Feature Value |
|---|---|
| Explosion safety category for dust (EF003998) | None |
| Construction type housing (EF004008) | Special construction |
| Type of switching contact (EF003591) | Slow-action switch |
| Degree of protection (NEMA) (EF011959) | Other |
| Degree of protection (IP) (EF005474) | IP67 |
| Type of interface for safety communication (EF003956) | None |
| Type of electric connection (EF003961) | Cable entry metrical |
| Type of interface (EF006977) | None |
| Housing material (EF001596) | Other |
| Explosion safety category for gas (EF003997) | None |
| With status indication (EF001602) | Yes |
| Suitable for safety functions (EF001597) | Yes |
| With escape release (EF007172) | Yes |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 1 |
| Guard locking force (EF007552) | 1300 N |
| Rated operation current Ie at AC-15, 230 V (EF001385) | 0 A |
| Rated operation current Ie at DC-13, 125 V (EF007085) | 0.27 A |
| Number of safety auxiliary contacts (EF006940) | 0 |
| Rated operation current Ie at DC-13, 24 V (EF007087) | 0 A |
| Rated operation current Ie at DC-13, 230 V (EF001386) | 0 A |
| Number of contacts as normally closed contact (EF008255) | 4 |
| Rated operation current Ie at AC-15, 125 V (EF007082) | 3 A |
| Width sensor (EF007094) | 88.5 mm |
| Rated operation current Ie at AC-15, 24 V (EF007084) | 0 A |
| Height of sensor (EF007283) | 35.5 mm |
| Length of sensor (EF007334) | 95 mm |
| Ambient temperature during operating (EF007515) | -10 °C |
| Rated control supply voltage magnet drive DC (EF007070) | 20.4 V |
