OMRON D4NL-4DFB-B D4NL-4DFB-B D4NL0272D D4NL4DFBB OMRON Lock makan desert/Opening solen.110vac 2NC+2NC LED M20 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4NL-4DFB-B D4NL0272D D4NL4DFBB OMRON Lock makan desert/Opening solen.110vac 2NC+2NC LED M20

D4NL-4DFB-B

D4NL0272D

D4NL4DFBB

OMRON

1 Pcs.

Lock makan desert/Opening solen.110vac 2NC+2NC LED M20 Locking /Opening solen.110VAC 2NC+2NC LED M20

Automation > Position switch with guard locking
D4DL/DS/DH/DR/GL/NL/NH/NS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed for industrial safety interlocking circuits, the Omron D4NL-4DFB-B D4NL0272D D4NL4DFBB OMRON Lock makan desert/Opening solen.110vac 2NC+2NC LED M20 serves as a robust lock mechanism designed to prevent unauthorized or hazardous access to machinery enclosures. Safety engineers install these solenoid-actuated switches on perimeter fencing and protective access doors to maintain safe operational states across automated plants. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Special construction
  • Type of switching contact (EF003591): Slow-action switch
  • Degree of protection (IP) (EF005474): IP67
  • Type of electric connection (EF003961): Cable entry metrical
  • With status indication (EF001602): Yes
  • Suitable for safety functions (EF001597): Yes
  • With escape release (EF007172): Yes
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 0
  • Guard locking force (EF007552): 1300 N
  • Rated operation current Ie at AC-15, 230 V (EF001385): 0 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.27 A
  • Number of safety auxiliary contacts (EF006940): 0
  • Rated operation current Ie at DC-13, 24 V (EF007087): 0 A
  • Rated operation current Ie at DC-13, 230 V (EF001386): 0 A
  • Number of contacts as normally closed contact (EF008255): 4

More info

▲
  • Safety door switch with electromagnetic lock or unlock mechanism
  • Models with four or five built-in contacts
  • Strong key holding force: 1300N
  • For standard loads and micro loads
  • Keys are compatible with D4GL and D4NS
