OMRON D4NL-2BFG-B D4NL-2BFG-B D4NL0029B D4NL2BFGB OMRON Lock solen 24vdc/Opening mecan 1NC/1NO+2NC LED G1/2 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4NL-2BFG-B D4NL0029B D4NL2BFGB OMRON Lock solen 24vdc/Opening mecan 1NC/1NO+2NC LED G1/2

D4NL-2BFG-B

D4NL0029B

D4NL2BFGB

OMRON

1 Pcs.

Lock solen 24vdc/Opening mecan 1NC/1NO+2NC LED G1/2 Guard lock safety-door switch, D4NL, Standard Release Key, Solenoid Lock/Mechanical Release, G1/2

Automation > Position switch with guard locking
D4DL/DS/DH/DR/GL/NL/NH/NS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

This Omron D4NL-2BFG-B Lock solen 24vdc/Opening mecan 1NC/1NO+2NC LED G1/2 is a safety switch with guard locking. Components of this type are routinely deployed on industrial machine guards and access doors to prevent operators from entering hazardous areas while machinery is in motion.

Please note that specific pricing, availability, and lead times are confirmed per enquiry through an RFQ.

  • Degree of protection (IP) (EF005474): IP67
  • Construction type housing (EF004008): Special construction
  • Type of switching contact (EF003591): Slow-action switch
  • With status indication (EF001602): Yes
  • With escape release (EF007172): Yes
  • Suitable for safety functions (EF001597): Yes
  • Number of contacts as change-over contact (EF008257): 0
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.27 A
  • Rated operation current Ie at DC-13, 24 V (EF007087): 0 A
  • Rated operation current Ie at AC-15, 125 V (EF007082): 3 A
  • Height of sensor (EF007283): 35.5 mm
  • Number of contacts as normally open contact (EF008256): 1
  • Guard locking force (EF007552): 1300 N
  • Rated operation current Ie at AC-15, 230 V (EF001386): 0 A
  • Number of safety auxiliary contacts (EF006940): 0
  • Rated operation current Ie at DC-13, 230 V (EF001386): 0 A

More info

▲
  • Safety door switch with electromagnetic lock or unlock mechanism
  • Models with four or five built-in contacts
  • Strong key holding force: 1300N
  • For standard loads and micro loads
  • Keys are compatible with D4GL and D4NS
