View larger
Images are for illustrative purposes only. Please refer to data sheet for details
D4NH-4CAS D4NH0040F D4NH4CAS OMRON Hinge axle Plastic 2NC/1NO Break-slow-M20
D4NH-4CAS
D4NH0040F
D4NH4CAS
OMRON
1 Pcs.
Hinge axle Plastic 2NC/1NO Break-slow-M20
Safety Limit switch, D4NH, M20 (1 conduit), 2NC/1NO (slow-action), shaft actuator
Automation > Hinge switch
D4DL/DS/DH/DR/GL/NL/NH/NS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲
Door switch typeHinge-operatedMaterial housingPlasticMaterial headPlasticActuator typeShaftDoor contacts NC2Door contacts NO1LED indicatorConnection methodTerminal blockCable length0 mDegree of protection (IP)IP67Conduit sizeM20Number of conduits1Switch actionSlow actionShapeCuboidOverall length of sensor82.5 mmHeight of sensor30 mmWidth of sensor31 mm
| Feature Name | Feature Value |
|---|---|
| Explosion safety category for dust (EF003998) | None |
| Construction type housing (EF004008) | Special construction |
| Type of switching contact (EF003591) | Slow-action switch |
| Degree of protection (NEMA) (EF011959) | Other |
| Coating housing (EF001601) | Other |
| Degree of protection (IP) (EF005474) | IP67 |
| Type of control element (EF006976) | Full shaft |
| Type of interface for safety communication (EF003956) | None |
| Type of electric connection (EF003961) | Cable entry metrical |
| Type of interface (EF006977) | None |
| Housing material (EF001596) | Plastic |
| Explosion safety category for gas (EF003997) | None |
| With status indication (EF001602) | No |
| Suitable for safety functions (EF001597) | Yes |
| Forced opening (EF006694) | Yes |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 1 |
| Rated operation current Ie at AC-15, 230 V (EF001385) | 3 A |
| Rated operation current Ie at DC-13, 125 V (EF007085) | 0.27 A |
| Number of safety auxiliary contacts (EF006940) | 25 |
| Rated operation current Ie at DC-13, 24 V (EF007087) | 0.27 A |
| Rated operation current Ie at DC-13, 230 V (EF001386) | 0.27 A |
| Number of contacts as normally closed contact (EF008255) | 2 |
| Rated operation current Ie at AC-15, 125 V (EF007082) | 3 A |
| Width sensor (EF007094) | 31 mm |
| Rated operation current Ie at AC-15, 24 V (EF007084) | 3 A |
| Height of sensor (EF007283) | 30 mm |
| Length of sensor (EF007334) | 82.5 mm |
