OMRON D4N-4D31 D4N-4D31 D4N 0350F D4N4D31 OMRON Plastic 3nc contact forms Slow Plunger M20 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-4D31 D4N 0350F D4N4D31 OMRON Plastic 3nc contact forms Slow Plunger M20

D4N-4D31

D4N 0350F

D4N4D31

OMRON

1 Pcs.

Plastic 3nc contact forms Slow Plunger M20 Plastic 3NC Slow Plunger M20 Limit switch, Top plunger, 3NC (slow-action), 3NC (slow-action), M20 (1-conduit)

Automation > End switch
D4N

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Plastic 3nc contact forms slow plunger M20 Omron D4N-4D31 switches function as safety interlocks and limit devices deployed to monitor physical access points on industrial enclosures and machinery. They ensure safe plant operations by interrupting control circuits when actuated.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Type of control element (EF006976): Plunger
  • Type of electric connection (EF003961): Cable entry metrical
  • Switching function (EF000189): Slow-action switch
  • Housing material (EF001596): Plastic
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 0
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A
  • Number of safety auxiliary contacts (EF006940): 0

More info

▲
  • Direct opening mechanism and approval by notified body
  • Rugged plastic housing with double insulation
  • Wide range of actuators
  • M12 connectors or terminal block with M20 conduit
