OMRON D4N-4C22 D4N-4C22 D4N 0281M D4N4C22 OMRON Plastic 2NC/1NO Slow Roller plunger Metal, M20 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-4C22 D4N 0281M D4N4C22 OMRON Plastic 2NC/1NO Slow Roller plunger Metal, M20

D4N-4C22

D4N 0281M

D4N4C22

OMRON

1 Pcs.

Plastic 2NC/1NO Slow Roller plunger Metal, M20 Plastic 2NC/1NA Slow Roller Metal M20 Limit switch, Roller lever (metal lever, resin roller), 2NC/1NO (slow-action), 2NC/1NO (slow-action), M20 (1-conduit)

Automation > End switch
D4N

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Industrial automation relies heavily on position switches to track linear movement and ensure proper mechanical sequencing throughout complex production cycles. The Omron D4N-4C22 combines a plastic housing with metrical cable entries and slow-action contacts, providing dependable performance for general positioning applications.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing: Cuboid
  • Degree of protection (IP): IP67
  • Alignment of the control element: Roller cam straight
  • Type of control element: Roller lever
  • Type of electric connection: Cable entry metrical
  • Switching function: Slow-action switch
  • Housing material: Plastic
  • Switching function latching: No
  • With status indication: No
  • Suitable for safety functions: Yes
  • Forced opening: Yes
  • Output electronic: No
  • Number of contacts as change-over contact: 0
  • Number of contacts as normally open contact: 1
  • Rated operation current Ie at AC-15, 230 V: 3 A
  • Rated operation current Ie at DC-13, 125 V: 0.55 A

More info

▲
  • Direct opening mechanism and approval by notified body
  • Rugged plastic housing with double insulation
  • Wide range of actuators
  • M12 connectors or terminal block with M20 conduit
