OMRON D4N-1C31 D4N-1C31 D4N 0289E D4N1C31 OMRON Plastic 2NC/1NO Slow Plunger roller plunger PG13,5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-1C31 D4N 0289E D4N1C31 OMRON Plastic 2NC/1NO Slow Plunger roller plunger PG13,5

D4N-1C31

D4N 0289E

D4N1C31

OMRON

1 Pcs.

Plastic 2NC/1NO Slow Plunger roller plunger PG13,5 Plastic 2NC/1NA Slow Roller plunger PG13.5 Limit switch, Top plunger, 2NC/1NO (slow-action), 2NC/1NO (slow-action), Pg13.5 (1-conduit)

Automation > End switch
D4N

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron plastic 2NC/1NO slow plunger roller plunger PG13,5, part number D4N-1C31, is a mechanical limit switch utilized in industrial machinery to monitor position, detect limits of travel, and provide feedback for interlocking safety circuits.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Type of control element (EF006976): Plunger
  • Type of electric connection (EF003961): Cable entry PG
  • Switching function (EF000189): Slow-action switch
  • Housing material (EF001596): Plastic
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 1
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A
  • Number of safety auxiliary contacts (EF006940): 0

More info

▲
  • Direct opening mechanism and approval by notified body
  • Rugged plastic housing with double insulation
  • Wide range of actuators
  • M12 connectors or terminal block with M20 conduit

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
