OMRON D4N-1C20 D4N-1C20 D4N 0271B D4N1C20 OMRON Plastic, 2NC+1NO Slow Lever washer for PG13,5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-1C20 D4N 0271B D4N1C20 OMRON Plastic, 2NC+1NO Slow Lever washer for PG13,5

D4N-1C20

D4N 0271B

D4N1C20

OMRON

1 Pcs.

Plastic, 2NC+1NO Slow Lever washer for PG13,5 Plastic 2NC+1NA Slow Roller Lever PG13.5 Limit switch, Roller lever (resin lever, resin roller), 2NC/1NO (slow-action), 2NC/1NO (slow-action), Pg13.5 (1-conduit)

Automation > End switch
D4N

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Omron D4N-1C20 safety position switch is commonly deployed on machine guards and safety doors to monitor physical access and halt hazardous industrial motion. These electromechanical switches break contacts reliably when actuated, protecting operators from moving parts in automated manufacturing cells.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Alignment of the control element (EF008793): Roller cam straight
  • Type of control element (EF006976): Roller lever
  • Type of electric connection (EF003961): Cable entry PG
  • Switching function (EF000189): Slow-action switch
  • Housing material (EF001596): Plastic
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 1
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A

More info

▲
  • Direct opening mechanism and approval by notified body
  • Rugged plastic housing with double insulation
  • Wide range of actuators
  • M12 connectors or terminal block with M20 conduit
