OMRON D4N-1B2G D4N-1B2G D4N 0257G D4N1B2G OMRON Plastic 2NC Slow Roller plunger Roller plunger adjustable metallic PG13,5 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4N-1B2G D4N 0257G D4N1B2G OMRON Plastic 2NC Slow Roller plunger Roller plunger adjustable metallic PG13,5

D4N-1B2G

D4N 0257G

D4N1B2G

OMRON

1 Pcs.

Plastic 2NC Slow Roller plunger Roller plunger adjustable metallic PG13,5 Plastic 2NC Slow Roller Roller Adjustable Metal PG13.5 Limit switch, Adjustable roller lever, form lock (metal lever, resin roller), 2NC (slow-action), 2NC (slow-action), Pg13.5 (1-conduit)

Automation > End switch
D4N

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron plastic limit switch (D4N-1B2G) functions as a dependable presence-sensing device deployed across automated production lines to monitor door interlocks, guard positions, and moving machine elements. Built with a slow-action mechanism and roller plunger operator, it interrupts or establishes control circuits when physical contact occurs. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Alignment of the control element (EF008793): Roller cam straight
  • Type of control element (EF006976): Adjustable roller lever
  • Type of electric connection (EF003961): Cable entry PG
  • Switching function (EF000189): Slow-action switch
  • Housing material (EF001596): Plastic
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 0
  • Rated operation current Ie at AC-15, 230 V (EF001385): 3 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A

More info

▲
  • Direct opening mechanism and approval by notified body
  • Rugged plastic housing with double insulation
  • Wide range of actuators
  • M12 connectors or terminal block with M20 conduit
