D4N-1A32-L D4N 0720M D4N1A32L OMRON Plastic 1NC/1NO Slow Plunger roller plunger 90º PG13,5
D4N-1A32-L
D4N 0720M
D4N1A32L
OMRON
1 Pcs.
Automation > End switch
D4DL/DS/DH/DR/GL/NL/NH/NS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Omron D4N-1A32-L is a slow-action plastic limit switch featuring a roller plunger designed for 90-degree cable entry. Mechanical position switches provide essential feedback signals in automation loops, signaling the presence, movement, or end-of-travel limits of machine components.
Final pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- M12 connector: D4N-9120
- M12 connector: D4N-9131
- M12 connector: D4N-9132
- M12 connector: D4N-9162
- M12 connector: D4N-912G
- M12 connector: D4N-912H
- M12 connector: D4N-9E20
- M12 connector: D4N-9E32
- M12 connector: D4N-9E62
- Durability 2: Mechanical
- Operating speed: Roller lever
- Operating frequency: 30 operations/minute max.
- Minimum applicable load: Resistive load of 1 mA at 5 VDC (N-level reference value)
- Protection against electric shock: Class II (double insulation)
- Pollution degree (operating environment): 3 (EN60947-5-1)
- Contact gap: Snap-action: 2x0.5 mm min Slow-action: 2x2 mm min
More info
▲Limit switch with plastic housing
The D4N series of limit switches in plastic housing is the ideal switch for all standard mechanical position detection applications both for safety and non-safety applications.
- Direct opening mechanism and approval by notified body
- Rugged plastic housing with double insulation
- Wide range of actuators
- M12 connectors or terminal block with M20 conduit
Order code1 | ||||||
|---|---|---|---|---|---|---|
Adjustable roller lever, form lock | ||||||
Adjustable roller lever, form lock | ||||||
Switches with MBB contacts
MBB (Make Before Break) contacts have an overlapping structure, so that before the normally closed (NC) contact opens the normally open (NO) contact closes.
Order code1 | ||||
|---|---|---|---|---|
Specifications
Durability2 | 15,000,000 operations min.3 | |
| 500,000 operations min. for a resistive load of 3 A at 250 VAC 300,000 operations min. for a resistive load of 10 A at 250 VAC | ||
1NO/1NC Contact (Snap-action)
If metal deposition between mating contacts occurs on the NC contact side, they can be pulled apart by the shearing force and tensile force generated when part B of the safety cam or plunger engages part A of the movable contact blade. When the safety cam or plunger is moved in the direction of the arrow, the Limit Switch releases.

1NC/1NO Contact (Slow-action)

2NC Contact (Slow-action)
