OMRON D4F-302-5D D4F-302-5D D4F 0047M D4F3025D OMRON Metal IP67 2NC/2NA Plunger Roller plunger 5m vert. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

D4F-302-5D D4F 0047M D4F3025D OMRON Metal IP67 2NC/2NA Plunger Roller plunger 5m vert.

D4F-302-5D

D4F 0047M

D4F3025D

OMRON

1 Pcs.

Metal IP67 2NC/2NA Plunger Roller plunger 5m vert. Metallic IP67 2NC/2NA Embolo Roldana 5m vert. Small Safety Limit Switch, 2NC/2NO slow-action, roller plunger, 5 m cable, vertical cable exit

Automation > End switch
Others

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed for heavy-duty feedback tasks, the Omron D4F-302-5D metal IP67 2NC/2NA plunger roller plunger switch provides dependable operational tracking and safety interlocking in automated assembly lines and moving machinery.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Construction type housing (EF004008): Cuboid
  • Degree of protection (IP) (EF005474): IP67
  • Alignment of the control element (EF008793): Roller cam straight
  • Type of control element (EF006976): Plunger
  • Type of electric connection (EF003961): With cable preassembled
  • Switching function (EF000189): Slow-action switch
  • Housing material (EF001596): Metal
  • Switching function latching (EF007447): No
  • With status indication (EF001602): No
  • Suitable for safety functions (EF001597): Yes
  • Forced opening (EF006694): Yes
  • Output electronic (EF006987): No
  • Number of contacts as change-over contact (EF008257): 0
  • Number of contacts as normally open contact (EF008256): 2
  • Rated operation current Ie at AC-15, 230 V (EF001385): 0.75 A
  • Rated operation current Ie at DC-13, 125 V (EF007085): 0.55 A

More info

▲
  • Slim-size housing
  • Direct opening mechanism
  • Roller or plunger actuators
  • Pre-wired versions
