OMRON CS1W-RPT01 CS1W-RPT01 CS1W0274F CS1WRPT01 OMRON Repeater Controller Link Cable lt /lt - gt /gt Cable View larger
Images are for illustrative purposes only. Please refer to data sheet for details

CS1W-RPT01 CS1W0274F CS1WRPT01 OMRON Repeater Controller Link Cable lt /lt - gt /gt Cable

CS1W-RPT01

CS1W0274F

CS1WRPT01

OMRON

1 Pcs.

Repeater Controller Link Cable-Cable Controller Link Cable Repeater-Cable

Automation > Fieldbus, decentr. periphery - communication module
Accessories

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An Omron Repeater Controller Link Cable (model CS1W-RPT01) serves to extend network transmission distances and link multiple segments within industrial automation and control architectures. Such network components facilitate reliable data exchange between programmable controllers and distributed peripheral devices across large plant floors. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
